touch panel weinviewTK6102i v5wv upgraded to new type MT6103iP 10.1'' HMI new and original
| Price: | US$ 190 / Piece |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | TT/WESTERN UNION/PAYPAL |
| Port of Export: | ShenZhen or HongKong |
Product Details
| Model No.: | TK6103iP 1wv | Brand Name: | Weinview |
|---|
| Certification: | |
|---|---|
| Specification: |
PCB Coating: N/A
Enclosure: Plastic Dimensions WxHxD: 271X213X36.4mm Panel Cutout: 260X202mm Weight: Approx. 1 kg Mount: Panel mount |
Packaging & Delivery
| Packaging: | 1 |
|---|---|
| Delivery/Lead Time: | 3-5 DAYS |
| Production Capacity: | 9999 |
Product Description
Display
Display: 10.1" TFT LCD
Resolution: 1024X600
Brightness: 400
Contrast Ratio: 600:1
Backlight Type: LED
Backlight Life Time: >25,000hrs.
Colors: 16.2M
LED Viewing Angle(T/B/L/R): 60/60/70/70
Touch Panel
Type: 4-wire Resistive Type
Accuracy: Active Area Length(X)¯2%,width(Y)¯2%
Memory
Flash: 128MB
RAM:128MB
Processor
32 bits RISC Cortex-A8 600MHz
I/O Ports
USB Host: USB 2.0X1
USB Client: USB 2.0X1(Micro USB)
Ethernet: N/A
COM Port: COM1:RS-232 4W
COM2:RS-485 2W/4W
COM3:RS-232 2W/RS-485 2W
RTC
Built-in
Power
Input Power: 24¯20%VDC
Power Isolation: Built-in
Power Consumption: 650mA@24VDC
Voltage Resistance: 500VAC(1 min.)
Isolation Resistance: Exceed 50MΩ at 500VDC
Vibration Endurance: 10 to 25Hz(X,Y,Z direction 2G 30 minutes)
Specification
PCB Coating: N/A
Enclosure: Plastic
Dimensions WxHxD: 271X213X36.4mm
Panel Cutout: 260X202mm
Weight: Approx. 1 kg
Mount: Panel mount
Environment
Protection Structure: NEMA4/IP65 Compliant Front Panel
Storage Temperature: -20®~60®C(-4®~140®F)
Operating Temperature: 0®~50®C(32®~122®F)
Relative Humidity: 10%~90%(non-condensing)
Software
EasyBuilder Pro
|
