stainless steel screw conveyor for powder

stainless steel screw conveyor for powder

Product introduction

Screw conveyor is an efficiency transportation equipment with power device, gear box, coupling, screw shaft, hanger bearing and support base. Screw shaft is made of several sections which connected with spline. With this special design, it can bear large load capacity and easy to dismounting.


Screw conveyor is special used for cement plant or transport powder in field working. It is applicable for transporting powder granular and small blocked bulk material, such as clay powder, cement, concrete, sand, stone, grain, coal etc. Also can complete the gathering, stirring, mixing, dehydrating, customizing material, unloading, stacking during conveyor.


Screw Conveyor Advantages

1.Adopt high-quality steel pipe with good integral rigidity.
2.Adopt universal ball joint, which facilitates installation, adjustment and steering.
3.Adopt standard parts and components, which makes it is convenient for transportation.
4.Adopt high-quality reducer with heavy-duty design, large torque and low noise.
5.Adopt high-quality middle-hoisting bearing and tail bearing.

Working principle


When the hollow axes with screw flight rotate along the jacketed trough, the bulk material feed into the trough and screw flight was hold of trough during running, the screw flight push the material and make the material do axial movement, simultaneity the material contact with the hollow shaft and jacketed trough full with cooling water and do heat transfer process. The cooled material can be discharged at the proper outlet at the bottom of trough or transport our at the end of trough.



Application


Screw conveyor is widely used in various industries, such as building materials, chemicals, electric power, metallurgy, coal, grain and other industries, for horizontal or inclined conveyor dust, granular materials and small block, such as coal, ash, slag, cement, food, etc. The material temperature is less than 200 degree centigrade.
It is not suitable for conveying perishable, viscous, easy caking materials.
