plywood cold press machine
| Price: | US$ 18500 / Set |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | t |
| Port of Export: | QINGDAO |
Product Details
| Model No.: | GLCP500-1800 | Brand Name: | GEELONG |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Nominal pressure:500T
Board inlet method:transverse Rated pressure:26Mpa Working table size:1370x2700mm Opening:1800mm Main cylinders diameter:2*ะค360(wuxi brand) Cylinders working stroke:1050mm High pressure hydraulic pump:25 ml/r Motor power:11kw Controlling methods:Full automatic and manual control also Contactor, circuit breakers...etc.Schneider Motor brand:Shandong huali manufactured Dimension :2700x1370x3700mm Column width:400mm Upper and bottom beam height:900mm Middle tray height:400mm Frames assembly methods:bolts connected Screws and bolts connected Frame main steel thickness:35mm Steel Model No.:Q235 Machine color:grey Engineering gray Total weight:Approx. 12500KGS Lifting cylinder:wuxi brand Hydraulic station valve:JINYUAN BRAND |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | 20 days |
| Production Capacity: |
Product Description
Plywood pre-press machine is also called plywood cold press machine. It is divided into upper cylinder pre-press machine and bottom cylinder pre-press machine. Before board slab comes into the plywood hot press, it need to be pre-pressed by plywood cold press machine. The veneers are boned together intially, the pre-press production method can shorten hot pressing cycle time and improve the plywood quality. The board slab is easy for delivery and reduce the distance between hot platens.
|
