cnc machined conveyor UHMW PE polyethylene uhmwpe plastic parts roller

Product Description
cnc machined conveyor UHMW PE polyethylene uhmwpe plastic parts roller
Roller is an important part of the belt conveyor, it accounts for 35% of the total cost of a belt conveyor, bear more than 70% of the resistance. Roller's role is to support the conveyor belt and the weight of the material. Roller must be flexible and reliable operation, reduce the friction with roller conveyor belt, to take up of the total cost of more than 25% of the conveyor belt conveyor life plays a key role. Therefore, the quality of the roller is particularly important.
Ultra-high molecular weight polyethylene (UHMWPE) the supporting roller is a new generation of plastic instead of steel of high-tech products, by the ultra-high molecular weight polyethylene pipe material, plastic, metal, bearings, metal shaft bearing and seal assembly and become a hi-tech product. I company specializing in the production of ultra-high molecular polyethylene belt conveyor roller is the main raw material ultra-high molecular weight polyethylene, and according to the change of the roller surface material, the manufacturing structure also made corresponding change, make its abrasion resistance, rotational coefficient is greatly improved, such as to make it compared with the metal roller or ceramic roller, has many obvious advantages in the use of performance, is China's best-selling ultra-high molecular polyethylene roller.
HTB1IXmkHpXXXXXkXpXXq6xXFXXXq
Characters of cnc machined conveyor UHMW PE polyethylene uhmwpe plastic parts roller
1. UHMW exhibits virtually no water absorption
2, Non-Toxic
3. Low coefficient of friction
4. Corrosion resistant
5. Abrasion and impact resistant chinese manufacturer direct sale standard idler roller
6. Wear Resistant
7. Dielectric
8. Weatherproof
HTB13mRRHpXXXXX5aXXXq6xXFXXXs

Property Unit Value
Density g/cm3 0.93-0.96
Average molecular weight g/mol 3million- 10 million
Tensile strength(23®C in air) MPa 24
Breaking strength Mpa 42
Tensile strain at break % 600
Flexural Strength Mpa 32
Compression Strength Mpa 32
IZOD KJ/m2 120
Charpy impact strength (notched) MJ/mm2 No break
Ball Indentation Hardness N/mm2 42
Shore D hardness 65-70
Abrasion % 70-80, steel = 100
Static Friction Coefficient ≤0.16
Kinetic Friction Coefficient ≤0.10
Water Absorption NIL
Elongation at break at 23 degree % 300
Heat Deflection Temperature ®C 85
Melt Temperature ®C 130-140
Suitable operating temperature range ®C minimum temperature: -269
Maxium temperature: 80

Roller main technical performance parameters:
(1) Run the drag coefficient ≤0.03.

(2) Cylindrical runout ≤0.7D (roller diameter).

(3)Into the water ≤5g (in accordance with international standards for water spray test).

(4) Pipe wall thickness: When the roller diameter of 159mm, the bearing of 6308, the pipe wall thickness of not less than 4.5mm.When the roller diameter of 194mm, the bearing of 6308, the pipe wall thickness of not less than 6.3mm .

(5) Bearing wall thickness: When the roller diameter of 159mm, the bearing of 6308, the bearing wall thickness of not less than 4mm.When the roller diameter of 194mm, the bearing of 6308, the bearing wall thickness of not less than 5mm.

(6) Roller axial load carrying capacity ≥20000N.

(7) Axial displacement ≤0.1mm.
