beer bottle filling machine for beer filling

Beer bottle filling line
The Filling Systems provide a wide range of automatic & manual isobaric (counter-pressure) beer bottling and canning machines including efficient semi-automatic rinser, filler & capper/ seamer monoblocks.

These beer filling lines can also be used for bottling a wide range of sparkling and still drinks such as water, wine, cider, kombucha, soft drinks and carbonated drinks.

The filling line we can provide 1000BPH Line, 2000BPH Line, 3000BPH Line, 5000BPH Line, 6000BPH Line, 8000BPH Line according to your brewery capacity.
Features:
1. Using the conveyor sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottle neck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough.
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed balanced pressure flow valve filling valve, filling fast, filling accurate and no liquid spit out.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.

Model BCGF24-32-10
Capacity（B/H） (330ml, 500ml, 720ml), 1000-8000Bottles
Bottle size Neck:φ20-50mm；Height：150-320mm
Filling precision ＜+1MM
Air pressure 0.4Mpa
Air consumption (m⊃3;/min) 0.3
Power（kw） 3.5
Weight（kg） According to filling machine
Dimension（L*W*H)（mm） According to filling machine
