XYD-130 Crawler Water Well Drilling Rig For Sale
| Price: | US$ 4000 / Set |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | tt, lc |
| Port of Export: | qingdao |
Product Details
| Model No.: | xyd-130 | Brand Name: | Master Machinery |
|---|
| Certification: | iso-9001 |
|---|---|
| Specification: |
XYD-130 crawler drilling rig Drilling depth 130m Maximum opening hole diameter 220mm End hole diameter 75mm Drilling pipe diameter 50mm Drilling angle 90®-75® Drilling rig weight 2600kg Vertical Spindle Spindle rotating speed 142 285 570r/min Spindle stroke 450mm Windlass Maximum lifting weight of a single rope 1600kg Lifting speed of a single rope 0.41 0.82 1.64m/s Drum diameter 140mm Wire rope diameter 13mm Drum capacity 27 M Mud pump Model horizontal single urn twin-action Displacement 9577l/min Maximum pressure 1.2mpa Working pressure 0.7mpa Water inlet pipe diameter 30mm Water outlet pipe diameter 20mm Triangular belt diameter B1575mm |
Packaging & Delivery
| Packaging: | wooden box |
|---|---|
| Delivery/Lead Time: | 3 days |
| Production Capacity: | 100 sets per month |
Product Description
Keywords:crawler drilling machine, hydraulic hard rock drilling machine 1.The features of XYD-130 crawler drilling rig
The drilling machine adopts automatic Telescopic drilling tower, which is supported by two high-strength oil cylinders. Save effort, safe and reliable, maximum for the user to create benefits.
The chassis adopts rubber track, light weight and low life cycle cost, which can reduce noise of vehicle running mechanism, reduce the vibration of the vehicle body,and reduce fuel consumption greatly. It can walk on urban roads without hurting the road surface.
The chassis is equipped with four high-strength threaded legs (or hydraulic high leg). The installation and adjustment is fast and convenient, it can be used for leveling of work plane, loading and unloading vehicle reduces the hoisting cost and improve efficiency,and can be used as auxiliary support when working.
The adoption of 48V electric starting diesel engine greatly reduces the labor intensity of the operator, especially in the cold season. When the diesel engine starts difficult, it shows greater superiority.
