XYD-130 Crawler Hydraulic Rotary Drilling Rig
| Price: | US$ 4000 |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | tt, lc |
| Port of Export: | qingdao |
Product Details
| Model No.: | xyd-130 | Brand Name: | Master Machinery |
|---|
| Certification: | iso-9001 |
|---|---|
| Specification: |
XYD-130 crawler drilling rig
Drilling depth 130m Maximum opening diameter 220mm Diameter of the end hole 75mm Drilling rod caliber 50mm Drilling angle 90®-75® Drill weight (no include power) 2600kg Spindle Spindle speed 142/285/570 r/min Spindle stroke 450mm Hoist Max single line hoisting capacity 1600kg Single line lifting speed 0.41/0.82/1.64 m/s Drum diameter 140mm Wire rope diameter 13mm Wire rope capacity 27m Mud pump Type horizontal single urn twin-action Displacement 95 /77L/min Maximum pressure 1.2mpa Work pressure 0.7mpa Water inlet caliber 30mm Water to exit caliber 20mm Triangle conveyer belt B1575mm |
Packaging & Delivery
| Packaging: | wooden box |
|---|---|
| Delivery/Lead Time: | 3 days |
| Production Capacity: | 100 sets per month |
Product Description
Keywords: Crawler Core Drilling Rig, Hydraulic Crawler Water Drilling Rig,
1.The features of XYD-130 crawler drilling rig
The drilling rig adopts the automatic Telescopic style with two high strength oil cylinder support, a set of hydraulic valve control rigs operating supine, which is time-saving, safe and reliable to maximize the benefits for users.
The chassis adopts rubber track, light weight and low life cycle cost, which can reduce noise of vehicle running mechanism, reduce car body vibration, and reduce fuel consumption greatly. It can walk on urban roads without hurting the road surface.
The chassis is equipped with four high strength threaded legs (or hydraulic high leg). The installation and adjustment is fast and convenient. It can be used for leveling of work plane, loading and unloading vehicle, which reduces the hoisting cost and improves efficiency and works as auxiliary support.
The rig uses 48V electricty to start the diesel engine , which greatly reduces the labor usage, especially in the cold season. When the diesel engine has difficulty activiting, this starting mode shows greater advantages.
Shandong Master Machinery Group Co.,Ltd.
Sales Manager: Kevin
Mobile Phone:0086-18865479507
Mail: *
WeChat: 18865479507
QQ: 256618593
TEL: 0086-537-3860909
Skype: 8618865479607
Whatspp: 008618865479507
Website: *
|
