XFold Rigs TRAVEL X8 Octocopter (RTF)

XFold Rigs X8 U5
Performance
Payload Capacity Optimal: 6.6 lb / 3 kg
Maximum: 21.8 lb / 9.9 kg
Flight Time Up to 15 minutes (depending battery capacity and conditions)
Transmitter
Model xFold / Futaba T8FG Super
Frequency 2.4 GHz
Number of Channels 14
Battery 7.2 VDC NiMH
Gimbal
Model xFold / Gremsy H3
Number of Axes 3
Capacity 3.7 lb / 1.7 kg
Camera Compatibility DSLR, mirrorless camera, or compact video camera up to 3.7 lb (1.7 kg)
FPV Camera
Resolution Not specified by manufacturer
Video Downlink - Analog
Frequency 5.8 GHz
Transmit Power 600 mW
Video Downlink - HD
Model Amimon CONNEX
Range 3300' / 1000m (outdoor; line-of-sight)
Latency > 1 ms
Frequency 5.1 to 5.8 GHz
Channel Selection Automatic frequency selection (AFS)
Multicast Mode Up to 4 receivers with no delay or quality degradation (requires separately available additional ground unit(s))
Encryption AES-128 and RSA 1024 for key exchange
Supported Resolutions 1080p: 60, 50, 30, 25, 24 fps
1080i: 60, 50 fps
525i: 60 fps (NTSC)
625i: 50 fps (PAL)
OSD Support MAVLINK telemetry-based
Connectivity Video
Air Unit:
1 x mini HDMI
Ground Unit:
1 x HDMI (Type A)

Antenna
Air Unit:
2 x MMCX
Ground Unit:
5 x SMA

Power
Air Unit:
8 to 26 VDC (3S to 6S)
Ground Unit:
7 to 19 VDC
Operating Temperature 32 to 113®F / 0 to 45®C
Dimensions Air Unit:
4 x 2.5 x 0.6" / 102 x 63.6 x 15.6 mm
Ground Unit:
5.1 x 3.5 x 0.8" / 129 x 89 x 20 mm
Weight Air Unit:
4.6 oz / 130 g
Ground Unit:
9.2 oz / 260 g
FPV Monitor
Size 7"
Panel IPS
Brightness 400 cd/m°
Contrast Ratio 800:1
Resolution 1280 x 800
Receiver Type: Dual diversity
Number of Channels: 32
Flight Controller
Supported ESC Output 400 Hz refresh frequency
Supported Transmitters PCM or 2.4 GHz radio with at least 4 channels
Working Range MC: 4.8 to 5.5 V
VU Input: 7.4 to 26.0 V (2S to 6S LiPo recommended)
Output (V-SEN Port Red Wire): 3 A at 5 V (burst current: 7.5 A)
Power Consumption MAX: 1.5 W (0.3 A at 5 V)
Normal: 0.6 W (0.12 A at 5V)
Operating Temperature 14 to 122®F / -10 to 50®C
System Requirements Assistant Software: Windows 8, 7, XP SP3
Hovering Accuracy (GPS Mode) Vertical: ¯2.6' / ¯0.8 m
Horizontal: ¯8.2' / ¯2.5 m
Max Angular Speed 200®/s
Max Tilt Angle 35®
Ascent/Descent Ascent: 19.7 ft/s / 6 m/s
Descent: 14.8 ft/s / 4.5 m/s
Weight MC: 1 oz / 27 g
PMU: 1 oz / 28 g
GPS: 1 oz / 27 g
LED: 0.5 oz / 13 g
Dimensions MC: 1.8 x 1.3 x 1.3" / 45.5 x 32.5 x 18.5 mm
PMU: 1.6 x 1.1 x 0.4" / 39.5 x 27.5 x 10 mm
GPS & Compass: 1.8 (diameter) x 0.4" / 46 (diameter) x 10 mm
LED: 1 x 1 x 0.3" / 25 x 25 x 7.0 mm
Telemetry
Model DJI iOSD Mini
Video Format NTSC
PAL
Supported Flight Control Systems WooKong-M
Naza-M
Naza-M V2
Power Requirement 6 V
Working Current 180 mA at 6 V (typical value)
