Widely Used PVC Water Stop for Concrete Joint

Contact information
Sales Manager:     Miss lurywen
Mobile Phone:       +86-13323183257
Tel:                        86-318-5106277
Fax:                       86-0318-5106277
Website:                *
Company:              Hengshui Jianfeng Engineering Rubber co., LTD.


Detail information of pvc waterstop
1.Item No. PVC waterstop ,pvc profile
2.Product
characteristics a. High-Elastic, high tensile strength, tear strength, non-toxic, non-pollution,
harmlessness, used in the waterproof of drinking-water pool.

b. Can be constructed on the wet base surface, especially adapting to the waterproof of rainy
areas.
c. Excellent Cohesiveness. It can paste ceramic tile right after completion.
3. Material EPDM, CR, Silicone, Santoprene, PVC...
4.color Blue white yellow
5. Size made at your requested special size
6. standards Excellent chemical and physical property, excellent oil, high/low temperature-resistant,
wearing-resistant, oil-resistant, dust-resistant.
7. Usage Rubber seal could stop air, water and dust enter the machine system, which could protect the
machine or parts to be healthy and working well.
8. Type various kinds of industry, machine and construction industry
9. Production
and shipment MOQ:100kg
Rapid production by machine
Production capacity: 10 ton / Day
Strictly quality controlling process
On-Time delivery
10. Packing Strong cartons or according to customers require
11. Deliver time 15 or 20 days upon receipt your order
12. Payment L/C,T/T,Western Union,paypal
13. Contact +86-15132836877


Description of pvc waterstop
PVC waterstop, being embedded in the concrete joints, acts as a continuous water tight diaphragm to
prevent any seepage of liquids in constructions joints which are subject to hydrostatic pressure. It is
designed for expansion or contraction joint; meanwhile, it can accommodate lateral and transverse
movements which make it capable to suit the moving joints.
The PVC waterstop is extruded form an elastomeric plastic material including high grade polyvinyl chloride, special resin and some chemical additives such as plasticizers and stabilizers




 Shapes of pvc waterstop
1. Plain web
Suitable for construction, kicker and partical contraction joints, where no
shear movement is possible.
2. Center Bulb
Suitable for subsidence, contraction expansion joints, including high
movement joints.
3. Other types


Typical Application of pvc waterstop
1.Agriculture: Dams, Canals, Aquaducts, Large Reservoirs, Irrigation Projects.
2.Public Utilities: Water Tanks, Swimming Pools, Tunnels, Concrete Roads, Water Filtration Plants,
Sewarage Disposal System,Neutralization Tanks, Bridges, Roads, Embankments, Municipal Hydraulic
Projects, Clarifiers.
3.Buildings: Basements & Foundations Floor Slabs,Terraces,Concrete Runways, Retaining Walls,Overhead
&Underground,Water Tanks,Multistoried Buildings.
4.Industries: Fertilizer, Steel, Effluent Treatment Plants, Thermal Power Stations, Atomic Reactors,
Shipyards & Docks, Cooling Towers.


Process of  pvc waterstop
Drawing--new tooling--samples confirm--mass production--shipping
