Weinviewold type MT6070iH5WV touch panel MT6070iH 5WV original model in stock MT6070iH

Display:7" TFT LCD

Brightness (cd/m2):375 cd/m2

Contrast Ratio:500:1

Color:65536

Resolution (WXH):800x480

Back Light:LED

Back Light Life Time:30,000 hr
Touch Panel Type:4 wires resistive type
Storage (RAM):128

RAM (RAM):64
SD Card Slot:N/A

USB Host:USB 1.1 x 1

USB Client:USB 2.0 x 1

Ethernet Port:N/A

COM Port:COM1(RS232 / RS485 2W/4W),COM2(RS232) COM3(RS232/RS485 2W)
Audio:N/A
Input Power:24 ¯20% VDC

Power Consumption:250mA@24VDC

RTC:Built-in

CE:Compilies with EN 55022:2006,Class A , EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005 standards

FCC:
UL:E248297

Voltage Resistance:500 VAC (1 min)

Isolation Resistance:Exceed 50MΩ at 500 VDC

Vibration Endurance:10 to 25 Hz (X,Y,Z direction 2G 30minutes)

Protection Structure:IP65 front panel (O ring seal)

Storage Temperature:-20®~60®C (-4®~140®F)

Operating Temperature:0®~45®C (32®~113®F)

Operation Humidity:10-90% RH (non-condense)
