WeinviewMT6071iE TOUCH PANEL 7'' TFT Display REPLACE old type MT6070iH3 Cortex-A8 32bit RISC 600MHz
| Price: | US$ 175 |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | TT/WESTERN UNION/PAYPAL |
| Port of Export: | ShenZhen or HongKong |
Product Details
| Model No.: | MT6071iE | Brand Name: | Weinview |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Sheathing material
Industrial plastics Outside measurement WxHxD 200.3 x 146.3 x 35mm Opening size(mm) 192 x 138mm Weight(kg) Approx.0.6 kg |
Packaging & Delivery
| Packaging: | 1 |
|---|---|
| Delivery/Lead Time: | 3-5 DAYS |
| Production Capacity: | 9999 |
Product Description
7” 800 x480 TFT LCD
Fanless cooling system
USB Client Port for downloading projects
COM2 and COM3 [RS485] support MPI 187.5K, please use one at one time
NEMA4/IP65 Compliant Front Panel
Built-in Power Isolation
Display type:7” TFT LCD
Resolution(WxH dots):800x480
Brightness(cd/m2) :350
Contrast:500:1
Backlight type:LED
Backlight service life:30,000 hours
colors:16M
Type:4-wire Resistive Type
Accuracy:Active Area Length(X)¯2%, Width(Y)¯2%
Flash RAM(MB):128
DRAM (MB):128
Processor:32 bits RISC Cortex A8 600MHz
USB Client:USB 2.0 x 1
USB HOST:USB 1.0 x 1
Ethernet:N/A
COM Port:COM1: RS-232, COM2: RS-485 2w/4w, COM3: RS-485 2w
RTC:Built-in
Input power"24¯20%VDC
Power dissipation:350mA@24VDC
Isolated power supply:Built-in
Pressure-proof:500 VAC(one min)
Insulating resistance:Exceed 50M @ 500VDC
Quake-proof:10 to 25Hz(X,Y,Z direction 2G 30 minutes)
Protection level:NEMA4 / IP65
Storage Temperature:-200 ~ 600 (-40 ~ 1400F)
Operating Temperature:00 ~ 500C(320 ~ 1220F)
Operating Humidity:10% ~ 90%@400C(No condensation)
CE Certification:CE
Software:EasyBuilder Pro V4.10.04 or later versions
|
