Weinview MT8071iE 7" Touch Screen Ethernet Interface HMI new and original
| Price: | US$ 205 |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | TT/WESTERN UNION/PAYPAL |
| Port of Export: | ShenZhen or HongKong |
Product Details
| Model No.: | MT8071iE | Brand Name: | Weinview |
|---|
| Certification: | |
|---|---|
| Specification: |
Shell Material: Engineering plastic
Dimension W*H*D:200.3 x146.3 x 34mm Hole Size:192 x 138 mm Weight:0.6kg |
Packaging & Delivery
| Packaging: | 1 |
|---|---|
| Delivery/Lead Time: | 3-5 DAYS |
| Production Capacity: | 9999 |
Product Description
Type:7”TFT
Resolution(WxH dots):800x480
Brightness(cd/m2):350
Contrast:500:1
Backlight type:LED
Backlight service life:>30,000 hours
Display colors:24 bits
Touch Panel:Four-wire analog resistance type
Touch-control precision:Active Area Length(X) ¯2%, Width(Y)¯2%
Flash RAM(MB):128
DRAM(MB):128
Processor:Cortex A8 32Bit RISC 600MHz
USB HOST:USB 2.0 x 1
Ethernet:10/100 Base-T
COM connectors:Com1:RS-232,Com2: RS-485 2w/4w,com3:RS-485 2w
Calendar:Built-in
Input power:24¯20%VDC
Power dissipation:350mA@24V
Isolated power supply:Built-in
Pressure-proof:500 VAC(one min)
Insulating resistance:Over 500MW at 500 VDC
Quake-proof:10 to 25Hz(Direction X,Y,Z 2G 30 mins)
Sheathing material:Industrial plastics
Outside measurement WxHxD:200.3 x 146.3 x 34mm
Opening size(mm):192 x 138
Weight(kg):About 0.6kg
Protection level: IP65 front panel protection level
Storage Temperature:-200 ~ 600 (-40 ~ 1400F)
Operating Temperature:00 ~ 500C(320 ~ 1220F)
Operating Humidity:10% ~ 90%RH(No condensation)
Software:EasyBuilder Pro V4.10.04
|
