Weinview 7'' HMI MT6070iH3 original type MT6070iH3WV touch panel MT6070iH 3WV old type in stock
| Price: | US$ 175 / Piece |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | TT/WESTERN UNION/PAYPAL |
| Port of Export: | ShenZhen or HongKong |
Product Details
| Model No.: | MT6070iH3 | Brand Name: | Weinview |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Sheathing material:Industrial plastics
Outside measurement WxHxD:200 x 146 x 42.5mm Opening size(mm):192 x 138 Weight(kg):About 0.85kg |
Packaging & Delivery
| Packaging: | 1 |
|---|---|
| Delivery/Lead Time: | 3-5 DAYS |
| Production Capacity: | 99 |
Product Description
Display type:7”TFT
Resolution(WxH dots):800x480
Brightness(cd/m2) :350
Contrast:500:1
Backlight type:LED
Backlight service life:30000 hours
Display colors:65536
Type:Four-wire analog resistance type
Flash RAM(MB):128 MB
DRAM(MB):64 MB
Processor:32Bit RISC 400MHz
SD Card Slot :N/A
USB Client:USB 2.0 x 1
USB HOST:USB 1.0 x 1
Ethernet:N/A
COM Port:Com1:RS-232/RS-485 2w/4w,Com2:RS232;com3:RS-485 2w
Calendar :Built-in
Input power:24¯20%VDC
Power dissipation:350mA@24VDC
Isolated power supply:Built-in
Pressure-proof:500 VAC(one min)
Insulating resistance:Over 500MW at 500 VDC
Quake-proof:10 to 25Hz(X,Y,Z 2G 30 minutes)
Protection level:NEMA4 /IP65 front panel protection level
Storage Temperature:-20C ~ 60C (-40 ~ 140F)
Operating Temperature:0C ~ 50C(32 ~ 122F)
Operating Humidity:10% ~ 90%@40C(No condensation)
CE Certification:CE
Software:EB8000 V2.0.0
|
