Description of rubber water stop
Rubber waterstop, made of quality SBR (styrene butadiene rubber),neoprene rubber or natural rubber, is one of the widest types for concrete structure to prevent liquid leaking in or out. Generally,designed to be cast in the concrete, rubber water stops are ideal for applications where high physical properties of rubber are required. For example,reservoirs, dams and other water retaining or excluding applications with  high movements or water pressure.



Features of rubber water stop
  High elasticity.
  High elongation.
  Excellent high movement accommodation.
  Capable to withstand high hydrostatic head.
  Adjust for subsidence and seismic movements.
  Hot vulcanized site joints.


Description index of rubber water stop


Description Index
1. Hardness ( Shore A ) 60¯5 60¯5 60¯5
2.Tensile strength ,MPa               ≥ 15 12 10
3.Elongation at break , %            ≥ 380 380 300
4.Compression set % 70®×24h,
%         ≤ 35 35 35
23®×168h,
%         ≤ 20 20 20
5. Tear strength ,KN/m                 ≥ 30 25 25
6.Brittleness temperature,           ≤ -45 -40 -40
7.Hot air
aging 70®×
168h Hardness (shoreA) +8 ------ _
Tensile strength,
MPa                  ≥ 12 10 _
Elongation at
break, %          ≥ 300 300 _
100®×
168h Hardness (shoreA) __ __ +8
Tensile strength,
MPa                 ≥ __ __ 9
Elongation at
break, %          ≥ __ __ 250
8. Resistance to ozone ageing
50pphm:20%,48h Grade2 Grade2 Grade0
9. Adhesion of rubber to metal With contact section in elastomer
10. Notes (1) Adhesion of rubber to metalis used
to the rubber water stop with steel edge.
(2) If there are other special requirements,
it could add inspection items properly
after making deal by both sides.When as
users'requirements to check mildew test
according to the circumstances, the
mildew proof property must be equal to
or over Grade 2.
