Watcher MMC-200 - Forming machine for protein, cereal, granola, muesli, seed mixes, coconut chips.

Waltcher MMC-200 - forming machine for protein, cereal, granola, muesli and seeds mixes, coconut chips, wafer crumbs or popcorn with sugar syrop or chocolate (white or dark)


Design features:
- Fully automatic control through the servo system.
- Top table type model.
- Suitable for small capacity.
- Stainless steel, aluminum and special ultraplastic.
- Multi partial pressure system.
- In-built special devices for inside mixing of the mass and unloading of formed products.
- An integrated conveyor system.
- Folding cantilever type transporter.
- Standard equipment for cereal mass.
- Accurate speed control.

Benefits:
- Compact: it takes up to 1.2 square meters.
- Forming of different shapes of product
- Forming without scrap and waste
- Cereals are not damaged
- High speed forming on the tape.
- Minimum resetting time
- Quick and easy cleaning
- Touch screen panel
- Quick change of the forming set
- Roll forming system is designed specifically for cereal.
- Custom-made rotor
- All parts having contact with the product are made from food-grade structural plastic and stainless steel


MMC-200
Working width in mm .: 200
Roller diameter in mm .: 200
Fully automatic operation
Electricity: 380 V, 50Hz, 3 phase
Power: 1.5 kW
Forming speed on belt, m / min: 0,2 - 2,8
Weight in kgs.: 200
Compressed air: 6 - 7 bar
Cycles / min .: 10 to 50
Air consumption: appr. 25 l / min
Dimensions, mm .:
Length: 800 mm
Width: 820 mm
The height (standard bunker): 1200 mm

Forming rotor for cereal (bars, balls, squares, rounds, hearts…)

Product shape: according request
Length: according request
Width / Diameter: according request
Height: according request

Forming rotor lubrication system

Capacity (maximum): 10,000 pieces / hour, or 210 kgs / hour.
Energy efficiency class: IE 3


Delivery time 4 - 5 monthes.
Delivery: from our warehouse in Krefeld, Germany.

Warrantee:
12 months or 2,000 operating hours (until one of two conditions in one-shift operation, with the exception of fast wearing parts)


*************************************************************
TERMS OF PAYMENT:
50% ADVANCED PAYMENT
50% BEFORE SHIPMENT
Title: goods remain our property until full payment.

Delivery time is confirmed when placing an order.
