UPVC window and door working machine
| Price: | US$ 15000 / Kit |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | L/C T/T |
| Port of Export: | QINGDAO |
Product Details
| Model No.: | LJZ2S-500X4200 | Brand Name: | SDWEM |
|---|
| Certification: | SGS |
|---|---|
| Specification: |
Main Feature
1.High quality carbide tipped saw blades. 2. High precision main shaft to keep saw blades running stability. 3. Pneumatic-hydraulic damp device to keep the stable feeding. 4.Adopt high quality guide railing system in the feeding system. 5.High precision linear bearing to keep the repositioning precision. 6.Quot turnable machine head. 7.Vertical and horizontal clamping cylinder. 8.Spraying cooling system. 9.Right head feeding adopts high helical pitch ball screw-lead motion, with high accurate driving, locating and smooth working. 10.Adopt CNC technique, can achieve various profiles auto cutting off. 11.which can realizes automatic cutting , automatic opening and shutting the shield and automatic feed . |
Packaging & Delivery
| Packaging: | Wooden case |
|---|---|
| Delivery/Lead Time: | 15 working days upon payment receipt |
| Production Capacity: | 100/month |
Product Description
Main Technique Parameter:
Power supply 380V 50Hz
Main motor power: 5.9kw
Air pressure 0.6-0.8M pa
Air consumption 200L /min
Main motor rotation speed: 2840r/min
Min/max Cutting length 435-4200mm
Saw blade dimension: Φ500×Φ30
Cutting angle: -45 ® 90 ® 45 ®
Cutting W x H 135x175mm/135x200mm
Repeat locating length ≤0.2mm
Angle cutting tolerance ¯5′
Plane of cutting surface ≤0.10
Cutting profile surface roughness Ra12.5³´µm
Size: (width × high × long) 5530mm × 1650mm × 1550mm
Weight: 2000Kg
|
