UCFL205 Two Bolts Flange Bearing 25*130*34mm Chrome Steel GCR15 SUNBEARING

Product Description

UCFL205 pillow block bearing

Product Name Pillow Block Bearing UCFL205
Structure Pillow block Bearing Seals Rubber Seal
Bore Size 25mm Bore Type Round
Outside Diameter 130mm Duty Type Medium Duty, Heavy Duty, and Others
Width 34mm Operating Temperature Range: -20 to +120®C
Material Plastic; Chrome Steel, Carbon Steel, Stainless Steel Lubrication Type: Oil; Grease;
Cage GCR 15, Stainless steel, etc. Series: UCFL
Certificate ISO9001:2008 Features Long life and high quality；Most competitive price, factory direct supply
Colour Blue Bearing Structure Spherical Surface Ball Bearing
The Number Of Rows Single Weight 0.63kgs
Clearance C2 C0 C3 C4 C5 Tolerance ABEC1 ABEC3 ABEC5 ABEC7



Insert bearings include screw locking style industrial series. These units combine a contact nitrile seal and an external slinger to provide superior protection from contamination and are adapted with a variety of housing styles. Insert bearings also include wide-inner-ring ball bearings that provide additional shaft support and locking options. These are designed for straight shafts and can be positioned without shoulders, locknuts, or adapters.



Product picture&2D Drawing of UCFL205 pillow block bearing
