Titanium ring,Titanium Forged Ring,titanium metal,Polished Titanium Ring,

1.Introduction
Corrosion resistance titanium ring
Titanium Forged Ring
Polished Titanium Ring
High strength titanium alloy rings
2. Materials & standards
Grade Grade1,Grade2,Grade5,Grade7,Grade9,Gr12
Standard ASTM B381 ASM,E SB381,ASTM F136/ ASTM F67/ AMS4928/DIN//JIS/ISO/BS
Technique Forged, Machined, sand blast or pickling surface
Condition (M), (R)
Shape Ring round
Surface Bright, Polished, Pickling, Acid cleaning
Note: Non-standard sizes are also available.
3. Chemical Requirements

4. Physical Properties
5. Production specifications
Product Dimensions Standards
Outer Diameter(mm) Inner Diameter(mm) Height(mm)
Ring 200~400 100~300 20~150 ASTMB381
400~700 150~500 30~250
700~900 300~700 35~300
900~1300 400~900 50~400
6. Allowable deviation
Product OD (mm) Deviation ID (mm) Deviation H (mm) Deviation
Ring 200~400 +3 / -1 60~300 +1 / -3 35~120 +3 / -1
>400~700 +4 / -2 150~500 +2 / -4 40~160 +4 / -2
>700~900 +5 / -3 300~700 +3 / -5 50~180 +5 / -3
>900~1300 +6 / -3 400-1000 +3 / -6 70~700 +6 / -3
