  • Titanium Flange Titanium Welding Neck Flange
  • Titanium Flange Titanium Welding Neck Flange
  • Titanium Flange Titanium Welding Neck Flange
scroll right

Titanium Flange,Titanium Welding Neck Flange , Titanium Blind Flange,Titanium Flange Bolt,Titanium F

Price: US$ 61 / Piece
Minimum Order: 5 Piece
Payment Terms: L/C,western union,T/T
Port of Export: shanghai
Product Details
Model No.: Brand Name: superbti
Certification: ISO9001
Specification: 1/2"~ 60"NB NPS 1/2 - NPS 24 (DN 10 - 2000)
Packaging & Delivery
Packaging: wooden case, cardboard case or customer request
Delivery/Lead Time: within 14 days
Production Capacity: 4000pcs per month
Product Description
1. Introduction
Titanium welding Flange
Titanium Lap Joint flanges
Titanium threaded flange
2. Materials & standards
Material Gr1,Gr2,Gr3,Gr4,GR5,Gr7,Gr9,Gr11
Standard ANSI6.5,STM B16.5,SMEB16.47,ISB2220,IN2627-2628,AWWA,ASTMA182,ASME SA182
size 1/2"~ 60"NB NPS 1/2 - NPS 24 (DN 10 - 2000)
Pressure PN0.25~32Mpa
(DIN) PN6 PN10 PN16 PN25 though PN250
150# 250# 300# 400# 500# 600# 900# 1500# 2500#
Technique Forged and CNC Machined
type Weld necks,Slip-Ons,Threaded Blind,Socket weld, Lap-Joint
surface FF RF TG RJ MFM
States (M) Annealed
Technology Casting、Forging、Cutting、Rolling and CNC Machining
3. Chemical Requirements
Grade N C H Fe O Al V Pa Mo Ni Ti
GR 1 0.03 0.08 0.015 0.20 0.18 / / / / / bal
GR 2 0.03 0.08 0.015 0.30 0.25 / / / / / bal
GR 5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal
GR 7 0.03 0.08 0.015 0.30 0.25 / / 0.12~0.25 / / bal
GR 9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal
GR 12 0.03 0.08 0.015 0.30 0.25 / / / 0.2~0.4 0.6~0.9 bal
4. Physical Properties
Grade State Tensile strength(min) Yeild strength (min) Elongation (%)
Ksi MPa ksi MPa
GR 1 (M)Annealed 35 240 20 138 24
GR 2 (M)Annealed 50 345 40 275 20
GR 5 (M)Annealed 130 895 120 828 10
GR 7 (M)Annealed 50 345 40 275 20
GR 9 (M)Annealed 90 620 70 438 15
GR 12 (M)Annealed 70 438 50 345 18
