Titanium Fasteners,Titanium Screw, Titanium Rod,Titanium Threaded Rod, Titanium Nut, Titanium Bolt,

1. Introduction
Titanium Tapping screws
Titanium Hexagon Screw
Titanium Flat Head Socket Cap Screws
Titanium Hex Cap Screws Fully Threaded
Titanium Screw Flat Head
2. Materials & standards
Material Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9, Gr12
Standard DIN 933, DIN912, DIN931, DIN913, DIN916, DIN7984, DIN6921, DIN7985, DIN963, DIN84, DIN7981
Size M1.6~ M64
Technique CNC Machining
States (M) Annealed
Surface Polishing, Anodizing, Black oxide
Note: Non-standard sizes are also available.
3. Characters
Low Modulus of Elasticity
Good thermal properties
Nonmagnetic and Non-toxic
Excellent Bearing to cryogenic property
Good resistance to effect of heat
Excellent Corrosion Resistance
Low Density and High Strength
4. Chemical Requirements
Grade N C H Fe O Al V Pa Mo Ni Ti
GR 1 0.03 0.08 0.015 0.20 0.18 / / / / / bal
GR 2 0.03 0.08 0.015 0.30 0.25 / / / / / bal
GR 5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal
GR 7 0.03 0.08 0.015 0.30 0.25 / / 0.12~0.25 / / bal
GR 9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal
GR 12 0.03 0.08 0.015 0.30 0.25 / / / 0.2~0.4 0.6~0.9 bal
5. Physical Properties
Grade State Tensile strength(min) Yeild strength (min) Elongation (%)
Ksi MPa ksi MPa
GR 1 （M）Annealed 35 240 20 138 24
GR 2 （M）Annealed 50 345 40 275 20
GR 5 （M）Annealed 130 895 120 828 10
GR 7 （M）Annealed 50 345 40 275 20
GR 9 （M）Annealed 90 620 70 438 15
GR 12 （M）Annealed 70 438 50 345 18
