Titanium Bike Brame, Titanium Handle Bar,Titanium Bike Fork, Titanium Road Frames,Titanium Mountain

1. Introduction
Titanium bike frame
Titanium handle bar
Titanium bike fork
Titanium bike component
Titanium road frames
Titaniummountain frames.
Titaniumtrack frames
2. Materials & standards
Grade Gr.9(Ti-3Al2.5V) and Gr.5(Ti-6Al-4V)
Shape Titanium Seamless tube
Technology Forging, rolling
Diameter 13mm, 31.8mm, 34.9mm, 38.1mm, 44mm
Weight about 1.4kg
Surface Polishing, sandblasted, drawing
Color Drawing surface treatment/laser marking
Condition (M)
Note: Non-standard sizes are also available.
3. Chemical Requirements
Grade N C H Fe O Al V Pa Mo Ni Ti
GR 5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal
GR 9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal
4. Physical Properties
Grade State Tensile strength(min) Yeild strength (min) Elongation (%)
Ksi MPa ksi MPa
GR 5 （M）Annealed 130 895 120 828 10
GR 9 （M）Annealed 90 620 70 438 15
5.Production specifications
Top tube OD31.8/34.9mm x T0.9mm
Head tube 34mm/44mm/Taperd 11/8-11/2"
Down tube OD38.1/40/42/44.5mm x T0.9mm
Seat tube OD31.8/34.9mm x T0.9mm (27.2 /31.6mm seat post)
Seat stay OD19mm x T0.9mm
Chain stay OD22.2/25.4mm x T0.9
