Standard water mold temperature controller
| Price: | US$ 700-1000 / Set |
|---|---|
| Minimum Order: | 1 SET |
| Payment Terms: | L/C,D/A,D/P,T/T,PAYPAL.MONEYGRAM |
| Port of Export: | Shanghai |
Product Details
| Model No.: | BWM-05B | Brand Name: | BUYING |
|---|
| Certification: | CE,ISO9001 |
|---|---|
| Specification: |
Standard water mold temperature controller specifications:
Model Unit BWM-05B BWM-10 BWM-20 BWM-30 BWM-50 BWM-75 Temp Range ℃ Normal Temperature-120℃ Temp Control Accuracy PID¯1℃ Power supply AC3φ380v 50HZ3P+E(5M) Heat transfer medium Water Cooling method Direct cooling Heating capacity KW 6 9 12 24/36 48/60 75 Pump Power KW 0.375 0.75 1.5 2.2 3.75 5.5 Pump Flow L/MIN 45 165 235 315 385 424 Pump pressure KG/CM2 2 2.2 2.5 3 3.8 4.3 Max powerconsumption KW 6.5/10 10 13.5/20 27/39 52/64 81 Alert function Pump reversal/oil shortage/overheating/overload/reverse turn Cooling water pipe INCH 1/2 1/2 1/2 1/2 3/4 3/4 Circulation oil pipe INCH 3/8*2 3/8*4 1/2*2 1 1.5 2 Size(L*W*H) MM 645*280*520 750*325*580 750*325*580 1200*420*1000 1350*500*1200 1650*500*1250 Weight KG 62 75 85 150 190 240 |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | 20 DAYS |
| Production Capacity: | Dust Proof Film + Anti-collision Foam + 5 Layer Cartons + Ply-wooded Case (For LCL only, no need fum |
Product Description
Production Description
*Explosive device pipe
*Blowing return function (optional)
*Return water temperature indicator
*Power automatic exhaust function of heating power switching
*Instant cooling power function
*BY-PASS relief of hot water loop
*Multi-point temperature control unit can be customized
*Pump horsepower and heating power can be customized
|
SUPPLIER PROFILE
|
|||
|---|---|---|---|
| Company: | Nanjing Buying Industrial Equipment Co., Ltd. | ||
| City/State | Nanjing,Jiangsu, Jiangsu | Country: |
China
|
| Business Type: | Export - Manufacturer / Trading Company | Established: | 2016 |
| Member Since: | 2017 | Contact Person | minxiu Gao |
