Standard PVC Water Stop Strap (made in China)

Contact information
Sales Manager:       Miss lurywen
Mobile Phone:         +86-13323183257
Tel:                         86-318-5106277
Fax:                        86-0318-5106277
Website:                 *
Company:               Hengshui Jianfeng Engineering Rubber co., LTD.


Description of pvc waterstop
PVC waterstop, being embedded in the concrete joints, acts as a continuous water tight diaphragm to prevent
any seepage of liquids in constructions joints which are subject to hydrostatic pressure. It is designed for
expansion or contraction joint; meanwhile, it can accommodate lateral and transverse movements which
make it capable to suit the moving joints.
The PVC waterstop is extruded form an elastomeric plastic material includinghigh grade polyvinyl chloride,
special resin and some chemical additives such as plasticizers and stabilizers


Detail information of pvc waterstop
1.Item No. PVC waterstop ,pvc profile
2.Product
characteristics 1. High-Elastic, high tensile strength, tear strength, non-toxic, non-pollution, harmlessness, used in the waterproof of drinking-water pool.
2. Can be constructed on the wet base surface, especially adapting to the waterproof of rainy areas.
3. Excellent Cohesiveness. It can paste ceramic tile right after completion.
3. Material EPDM, CR, Silicone, Santoprene, PVC...
4.color Blue white yellow
5. Size made at your requested special size
6. standards Excellent chemical and physical property, excellent oil, high/low temperature-resistant, wearing-resistant, oil-resistant, dust-resistant.
7. Usage Rubber seal could stop air, water and dust enter the machine system, which could protect the machine or parts to be healthy and working well.
8. Type various kinds of industry, machine and construction industry
9. Production
and shipment MOQ:100kg
Rapid production by machine
Production capacity: 10 ton / Day
Strictly quality controlling process
On-Time delivery
10. Packing Strong cartons or according to customers require
11. Deliver time 15 or 20 days upon receipt your order
12. Payment L/C,T/T,Western Union,paypal
13. Contact Welcome to contact us.


Features of pvc waterstop
1.High tensile strength.
2.Superior elongation capability.
3.Excellent inherent elasticity and impermeability
4.High resistance to acids, ozone, seawater even diesel oil.
5.Extremely alkalis, chlorinated water and other waterborne chemicals resistant.
6.Not susceptible to fatigue deterioration as with metal or rubber.
7.High quality meet even exceed the industrial standard.
8.Never discolor concrete.
9.No electrolytic action with surrounding metals.
10.Capable to withstand hydrostatic pressure.
11.Heat weldable in conjunction with electric splicing irons.
12.Withstand the expansion and contraction movement of the joints.
13.Capable to taking care of any deflection or displacement arising caused by temperature changing or
differential settlement of foundation.
14.Supplied in coils for easy handling with high flexibility.
15.Easy to install by tethering the outer flanges of the PVC waterstop to adjacent a reinforcing bars.


Shapes of pvc waterstop
1. Plain web
Suitable for construction, kicker and partical contraction joints, where no shear movement is possible.
2. Center Bulb
Suitable for subsidence, contraction expansion joints, including high movement joints
3. Other types



Typical Application of pvc waterstop
Agriculture: Dams, Canals, Aquaducts, Large Reservoirs, Irrigation Projects.

Public Utilities: Water Tanks, Swimming Pools, Tunnels, Concrete Roads, Water Filtration Plants,Sewarage
Disposal System, Neutralization Tanks, Bridges, Roads, Embankments, Municipal Hydraulic Projects,
Clarifiers.

Buildings: Basements & Foundations Floor Slabs,Terraces,Concrete Runways, Retaining Walls,Overhead &
Underground,Water Tanks,Multistoried Buildings.

Industries: Fertilizer, Steel, Effluent Treatment Plants, Thermal Power Stations, Atomic Reactors, Shipyards
& Docks, Cooling Towers.




Process of pvc waterstop
Drawing--new tooling--samples confirm--mass production--shipping
