Secukey WIFI Video Intercom Access

Vcontrol 2
WIFI Video Intercom Access
Intercom

> 2.4G WiFi connection,

> Android and iOS available

> Full duplex voice intercom

> 2MP+wide angle camera and night vision

> Support TF card with unlimited capacity

> Support motion detection, playback, take picture/video, unlock remotely

Access Control

> Touch key with one relay, 1000 users (988 common+2 panic+10 visitor)

> PIN Length: 4~6 digits

> EM card, Mifare card optional

> Wiegand 26~44 bits in put & output

> Can be used as Wiegand reader with LED & buzzer

> User data can be transferred

> 2 devices can be interlocked for 2 doors
Video Intercom

Network

2.4G WiFi connection

Pixel

2.0Mpx (1080P)

Visual Angle

Horizontal 140® wide angle

Night Vision

IR-CUT (Colorful at daytime, black and white at night)

Extended Memory

TF card with unlimited capacity

Intercom

Full duplex voice intercom

Other Functions

Motion detection; Playback; Take picture/video; Unlock remotely

Access Control

User Capacity

Common User
Visitor User
Panic User

1000

988

10
2

PIN Length

4~6 digits

Proximity Card Reader
Radio Technlogy
Read Range

EM or Mifare
125KHz/13.56MHz
2~6cm

Wiring Connections

Relay output, exit button, alarm, door contact, Wiegand input/output

Relay

Adjustable Relay Output Time

Lock Output Load

One (NO, NC, Common)

0~99 Seconds (5 seconds default)

2 Amp Maximum

Wiegand Interface

PIN Output

EM card version: Wiegand 26~44 bits input & output (Factory default: Wiegand 26bits)

Mifare card version:Wiegand 26~44 bits input & output (Factory default: Wiegand 34bits)

4 bits,8bits (ASCII),10 digits Virtual Number(Factory default:4bits)

Electric

Operating Voltage

Idle Current
Active Current

DC 12V

≤ 150mA
≤ 250mA

Environment

Operating Temperature

Operating Humidity

Indoor

-20®C ~ 60®C (-4®F ~ 140®F)

0%RH ~ 86%RH

Physical

Color

Dimensions

Unit Weight

Shipping Weight

Zinc-Alloy

Sliver & Black

L149 x W70 x H25 (mm)

400g

510g
