Saiheng SH-280/400/600/800/1000/1200 Beef Jerky Oven
| Price: | Contact for latest price |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | T/T |
| Port of Export: | Xingang |
Product Details
| Model No.: | SH-280/400/600/800/1000/1200 | Brand Name: | Saiheng |
|---|
| Certification: | CE,BV,SGS,ISO |
|---|---|
| Specification: |
Electric Type
Model SH-280 SH-400 SH-600 SH-800 SH-1000 SH-1200 Each Part(m) 4 4 4 4 4 4 Dimension(m) 16*0.64*1.1 28*0.92*1.35 40*1.1*1.45 40*1.3*1.45 60*1.76*1.6 60*1.96*1.6 Baking Temp.（℃） 190-240 190-240 190-240 190-240 190-240 190-240 Electric Power Needed (kw) 55 190 240 320 480 560 Weight (kg) 1800 8400 12000 16000 37500 45000 Gas Type Model SH-280-1 SH-400-1 SH-600-1 SH-800-1 SH-1000-1 SH-1200 Each Part(m) 4 4 4 4 4 4 Dimension(m) 16*1.2*1.8 28*1.45*1.8 40*1.6*1.8 40*1.8*1.7 60*1.85*1.8 60*1.96*1.6 Baking Temp.（℃） 190-240 190-240 190-240 190-240 190-240 190-240 Power(kw) 6 6 11 18 17 560 Weight (kg) 2000 7000 15000 30000 40000 45000 |
Packaging & Delivery
| Packaging: | Plastic film and wooden box |
|---|---|
| Delivery/Lead Time: | 40 days after confirming the deposit |
| Production Capacity: | Depends |
Product Description
1.Electric Type
This tunnel oven is composed of oven tunnel, mesh belt , belt driving system, chimney, electric heating pipes and control cabinet.
The heater adopts infrared heating to make the biscuit baking equally.
Frequency inverts control cabinet makes more accurate temperature controlling and wider temperate regulate range
The oven is separate to several individual heating zones as per different formulas. Each Zone has can be regulated individually.
2. Gas Type
1)The machine is heated with gas(LPG or natural gas).Rapid heating up and energy saving.
2)The oven is grouped into heat control zones. The top and bottom heat are independently adjustable and preset. The measured temperature and preset temperature will be displayed in digital form.
3)To allow independent movement of the chamber to relieve stresses when expanding or contracting.
4)High-quality thermal insulating material is used to get good insulation and efficient fuel usage.
5)Steel work, ducts and chambers paint with high temperature (400゜C) silvery paint. Outer covers paint with hard finish gloss paint.
6)Oven band level:1100mm
7)Fully automatic PID temperature control and automatic constant temperature.
8)Highest temperature:360゜C
9)Great control flexibility and prefect safety precautions.
10)Available in Lengths from 30 to over 150 meters.
11)Programmable logic controllers (PLC) and touch-screen control system are used.
12)It can meet the technological requirements for production of different meat.
For more details,plz feel free to contact us!
