SUNBEARING Pillow Block Bearing UCFL203 Blue 17*113*31mm Chrome Steel GCR15

Product Description



Product Name

Pillow Block Bearing UCFL203

Structure

Pillow block Bearing

Seals

Rubber Seal

Bore Size

17mm

Bore Type

Round

Outside Diameter

113mm

Duty Type

Medium Duty, Heavy Duty and Others

Width

31mm

Operating Temperature Range:

-20 to +120®C

Material

Plastic; Chrome Steel , Carbon Steel , Stainless Steel

Lubrication Type:

Oil; Grease;

Cage

GCR 15, Stainless steel etc.

Series:

UCFL

Certificate

ISO9001:2008

Features

The shaft is secured by grub screws on the inner ring

Colour

Blue

Bearing Structure

Spherical Surface Ball Bearing

The Number Of Row

Single

Weight

0.4kgs

Clearance

C2 C0 C3 C4 C5

Tolerance

ABEC1 ABEC3 ABEC5 ABEC7



Model: UC series, UCF series, UCFL series, UCT series, UCP series , and etc.

Application: Mining industry, Metallurgy, Textile, and etc.

Description: Pillow block bearing is a bearing unit that combine the rolling bearing and bearing seating together. Most insert bearings make the outer diameter a sphere. The structure varies in form and easy in installation. Also this kind of bearing has good versatility and interchangeability. It can easily work in severe environment.

Pillow block bearing simplifies outside structure of the machinery, making it more reasonable in assembling and maintenance, plus, it is with aligning property so that to protect torque load induced by assembling mistakes. In addition, as it is easier to be assembled on machine and lateral wall, it could be used on frame or anywhere of the machine Due to features mentioned above, the insert bearings with housings are used extensively as well as different types of the bearings themselves.
