STEEL MICRO PERFORATION PUNSH MACHINE ROLL FORMING ROLLER SHUTTER FORMING MACHINE
| Price: | US$ 27500 / Set |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | 30% advance payement; 70% by delivery |
| Port of Export: | Izmir Turkey |
Product Details
| Model No.: | YCL MICRO PERFORATION | Brand Name: | YUCESAN |
|---|
| Certification: | CE, ISO 9001, ISO 14001, ISO 2001 |
|---|---|
| Specification: |
2 cilindirs of Ø80 made out of special 4140 steel,
-molds 4140 special steel, -sheet thickness 0,60-1,20 mm sheet puching feature, -143 – 184 – 190 mm sheet metal punching feature, -PLC touch screen, -precision punched hole stitches Ø5 (DIN9861 Form DA&D), -AC Servo motor 220V , 3000 RPM , redactor (1/40), -hydaulic system unit 2,2 kw, -pressure Hour and Oil Level Display, -Emergency stop for safety, -chassis Body: 6-12mm steel construction, - Fire Chip Discharge Channel, -Portable Wheeled Body, -Fully Autimatic 380 volt, -Painting System Completely Electrostatic, -2 Engines and Photocell Roll Opener. |
Packaging & Delivery
| Packaging: | STANDART |
|---|---|
| Delivery/Lead Time: | 45 working days after receiving the advance payment |
| Production Capacity: | 30 Machine/ Month |
Product Description
STANDART CHARACTERISTICS
• Raw Material to be used: Galvanized Steel, Aluminium, Stainless Steel Black Steel
• Sheet Width:Min. 130mm-200mm
• Sheet Thickness: 0,60mm- 1,20mm,
Perforation Diameter: 3mm
DECOILER
• Outer diameter of the coil: 1.200 mm
• Width of the coil: Max. 300 mm
• Load capacity: 1,000 kg
• Options: Electric Handling: Electric Motor with two (2) photo-cell units
Two Decoiling Units with every machine
|
