SOQP-8540-10

SINOVO Telecom 40G QSFP-LR4 recently announced the completion of the development and validation client sample test. 40G QSFP-LR4 transceiver configuration has four CWDM channels, each operating rate of 10.3Gbps, can meet every channel 11.2GB / S transmission, compatible with QDR / DDR infiniband protocol standards, can be transmitted through a single-mode fiber is the maximum distance 10KM. This product with Gigalight on the market QSFP-SR4 has now formed the bulk of the data center to provide a complete portfolio of light module series. QSFP-SR4 used for 300 meters among devices within the optical connector applications. 40G QSFP-LR4 product internal temperature stable optical integrated transmitter and receiver devices at room temperature module total power consumption of less than 1.5 watts, the high temperature is less than the total power consumption 2.0 watts. Temperature (0-70 degrees) In the range the standard sensitivity specification not lower than-13.1dbm.
Parameters:
4 independent full-duplex channels Up to 10.5Gbps data rate per channel
MTP/MPO optical connector
850nm VCSEL laser transmitter
100m over OM3 MMFand 150m over OM4 MMF
Single +3.3V power supply
Operating case temperature range: 0~70®C
Low power dissipation
RoHS-6 compliant
Compliant with QSFP+ MSA
Application
40G Ethernet
Infiniband 4x SDR DDR QDR
