Price List 6 Inch flange cast iron valve rising stem resilient seat 300mm hand wheel Gate Valve pric

Product Name
casting iron din3352 f4 f5 resilient gate valve factory price
Materials
Ductile iron,Casting
Nominal diameter:
DN40-400 / 1.5inch-24inch
Temperature range:
0℃-80℃
Working Pressure
PN10/16
Suitable medium:
fresh water,waste water,sewage,air,food,oil etc.
Face to Face:
DIN3352-F4/F5
Connection Ends
Flange to BS EN 1092-2:1997
Stem
Stainless Steel,Carbon steel
Color
Clients' requirement
Standard:
(1)Design and manufacture: DIN3352 F4,F5, BS5163, BS5150, , EN593, GB/T12238
(2)End connection: DIN2543-2550, EN1092, AS2129, ISO 5211
(3)Wall thickness: APBS1868
(4)Face to face (end to end): EN 558, DIN3202, ISO5752, BS5155
(5)Inspection and test: EN12266-1, BS6755, ISO5208

Materialfor main parts:
(1)Body: Cast Iron or Ductile Iron
(2)Disc: Ductile Iron coated with EPDM Or NBR
(3)Stem: SS416, SS410, SS304, SS316,SS431
(4)Seat: NBR, Hypalon, EPDM, Neoprene, NBR, Wear-Resistant EPDM, Viton, Silicon, Heat-Resistant EPDM, White NBR, White EPDM, EPDM, PTFE
Coating: Fusion bonded epoxy power coated 250um Min
Connection type: Flanged type, Push-on type, Mechanical Joint type, Plain ends type
Sealing: Soft sealing or metal-to-metal seat, Flexible graphite
Operation: Manual, Pheunatic, Electric, Hydraulic and Pnewmatic-Hydraul
Appropriate medium: Air, water, sewage, steam, coal gas, oil
Packaging: Export polywood cases, or as per customers' requirements
