Plasma Deposition PVD Vacuum Coating Machine Chemical Vapor Deposition Film Coating System
| Price: | US$ 37300 |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | L/C T/T D/P Western Union Paypal Money Gram Others |
| Port of Export: | Zhengzhou,Qingdao,etc. |
Product Details
| Model No.: | CY-PECVD-450 | Brand Name: | CYKY |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Type CY-PECVD-450 Vacuum chamber front opening door,φ300mm X 300mm,stainless steelviewing window:φ100mm with baffle Vacuum pump set Front stage pump: rotary vane pump pumping speed is 1.1L/sSecondary pump: Turbo molecular pump pumping speed 600L/s Limiting vacuum 10-6Pa10-4Pa(Within 30 minutes) Vacuum(deposition) 0.133~133Pa,adjusted according to the process RF power 13.56MHz,500W (automatch) Flow control mass flowmeter(default Ar,0~200sccm) Dimensions 1100mm x 800mm x1100mm |
Packaging & Delivery
| Packaging: | Wooden Box Outside, Plastic Paper Inside |
|---|---|
| Delivery/Lead Time: | 30 days |
| Production Capacity: | 100 Sets/Month |
Product Description
CY-PECVD-450 chemical vapor deposition adopts plasma enhanced chemical vapor deposition technology, which can use high-energy plasma to promote the reaction process, effectively increase the reaction speed and reduce the reaction temperature. It is suitable for depositing thin films of silicon nitride, amorphous silicon and microcrystalline silicon on different substrates such as optical glass, silicon, quartz and stainless steel. It has good film-forming quality, less pinholes and is not easy to crack. It is suitable for the preparation of amorphous silicon and microcrystalline silicon thin film solar cell devices. It can be widely used in the scientific research and small batch preparation of thin film materials in Colleges and universities and scientific research institutes.
|
