Pertinax milling machine
| Price: | US$ 28300 / Set |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | T/T |
| Port of Export: | shenzhen |
Product Details
| Model No.: | PERTINAX-1010S | Brand Name: | Shenzhen Dyhua Intelligence |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Item Parameters
PERTINAX-1010S PERTINAX-1010S-ZD 1 Spindle speed Rotating speed 1000-60000RPM Rotating speed 1000-60000RPM 2 Spindle power 1.2 KW 1.2 KW 3 Cutting speed 3000mm/min 3000mm/min 4 Working area 1060mm*1080mm 1060mm*1080mm 5 Cutting tolerance ¯0.03mm ¯0.03mm 6 Spindle tolerance <0.005mm <0.005mm 7 Repeat tolerance ¯0.01mm ¯0.01mm 8 Tool tolerance <0.005mm <0.005mm 9 File Format DXF,CF2 DXF,CF2 10 Table height 1.1m 1.1m 11 Operate style Follow-up&CNC Follow-up&CNC 12 Power supply Three phase 380V¯5%\50/60HZ Three phase 380V¯5%\50/60HZ 13 Oscillating tool for cutting rubber optional yes 14 Plot(Draw) optional optional |
Packaging & Delivery
| Packaging: | standard seawood |
|---|---|
| Delivery/Lead Time: | 30days |
| Production Capacity: | 10/month |
Product Description
PERTINAX-1010S(Features)
1.We develop our own Pertinax counter making machine software, it can automatically generate creasing line according Dieboard figures before cutting.
2.Equipped with 1.2KW auto change tool high speed spindle and 6 tools to slot,position hole,chamfer,cut off and make mark.Our software automatically generates best paths to produce high quality and efficient products.
3.Z-axis adopts exclusive design control mode,auto aligning instrument and follow-up processing way.computer adjust the depth to ensure the operation simplicity and steady slotting depth.It can effectively avoid the depth control difficulties of other control methods and reduce the problems caused by materials.
4.Oscillating tool option for cutting rubber function.
5.High efficiently vacuum design to keep the surface clean.
6.Complete machine hardware interlock protection, preventing from the wrong signals to damage spindle.
|
