Pertinax milling machine
| Price: | US$ 46800 / Set |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | T/T |
| Port of Export: | shenzhen |
Product Details
| Model No.: | PERTINAX-1010 | Brand Name: | Shenzhen Dyhua Intelligence |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Item Parameters
PERTINAX-1010 PERTINAX-1010-ZD 1 Spindle speed Rotating speed 1000-60000RPM Rotating speed 1000-60000RPM 2 Spindle power 0.35 KW 0.35 KW 3 Cutting speed 3000mm/min 3000mm/min 4 Working area 1000mm*1080mm 1000mm*1080mm 5 Cutting tolerance ¯0.02mm ¯0.02mm 6 Spindle tolerance <0.005mm <0.005mm 7 Repeat tolerance ¯0.01mm ¯0.01mm 8 Tool tolerance <0.005mm <0.005mm 9 Table height 1.1m 1.1m 10 File Format DXF,CF2 DXF,CF2 11 Operate style Follow-up&CNC Follow-up&CNC 12 Power supply Three phase 380V¯5%\50/60HZ Three phase 380V¯5%\50/60HZ 13 Oscillating tool for cutting rubber Optional Yes 14 Plot(Draw) Optional Optional |
Packaging & Delivery
| Packaging: | standard seawood |
|---|---|
| Delivery/Lead Time: | 30days |
| Production Capacity: | 10/month |
Product Description
PERTINAX-1010/1010-ZD(Features)
1.We develop our own Pertinax counter making machine software, it can automatically generate creasing line according Dieboard figures before cutting.
2.Using four pieces import high-speed and high-precision spindles, for slotting, location holes, chamfer, cutting off. Our software automatically generates best paths to produce high quality and efficient products.
3.Oscillating tool option for cutting rubber function.
4.With the follow-up head processing methods to ensure the depth of processing slot stability. Reduce the problems of materials.
5.High efficiently vacuum design to keep the surface clean.
6.Complete machine hardware interlock protection, preventing from the wrong signals to damage spindle.
|
