PDF Series 300-500W Full brick power supply

PDF Series 300-500W Full brick power supply.Product details are as follows:
※Features
●Wide range of input voltage
●Design for high reliability,long lifetime
●Under-voltage protection for input
●Full load efficiency up to 88%
●High voltage input,high output power
●Wide range of power,easy toupgrade
Conditions:All specifications are tested under the room temperature 25℃, normal input voltage and pure negative normal load.
※Input Characteristic
Voltage Range
24VDC (Normal Rated Value): 18～36 VDC
48VDC (Normal Rated Value): 36～72 VDC
110VDC (Normal Rated Value): 66～154 VDC
300VDC (Normal Rated Value):200-400 VDC
※Output Characteristic
●Voltage set-point accuracy ……¯2%
●Line Regulation (full load) ……¯0.5%
●Load regulation (20%-100%load) ……¯0.5%
※General Characteristic
●Switching frequency ………200-350 KHz
●Isolation resistance ………200 MΩ
※Isolation voltage
●Input-output: >1500 VDC
●Input-case: >1050 VDC
●Output-case: >500 VDC
※Environmental Characteristic
●Substrate Working Temperature ………Industry: -40-+100℃
●Storage temperature ……………………Industry: -45-+105℃
※REM Features
Positive Logic:High level or no connect working
※Dimensions:116.80*61*12.70mm
※Protection Features
●Input under voltage protection ●Output short circuit protection
●Input over voltage protection        ●Output over current protection
●Output over voltage protection       ●Over temperature protection
※Model selection
Input Voltage (V) Input Voltage Range (V) Output Voltage (V) Output Current (A) Ripple pk-pk (mv) Efficieency (Typ) Models
Single 24 18-36 24 20.8 200 88% PDF500-24S24
48 36-72 24 20.8 200 89% PDF500-48S24
110 66-154 24 20.8 200 89% PDF500-110S24
300 200-400 12 33.3 120 88% PDF400-300S12
300 200-400 24 20.8 200 88% PDF500-300S24
300 200-400 28 17.8 280 88% PDF500-300S28
300 200-400 48 10.4 300 89% PDF500-300S48

 Remark:Only typical models are listed. For other models, please determine the power, input voltage and output voltage and send an email to *.
