PAB-W Series 200-300W Power Modules 5V 12V 24V
Price: | US$ 102 |
---|---|
Minimum Order: | 50 |
Payment Terms: | TT/LC/Paypal/Western union |
Port of Export: | Shanghai |
Product Details
Model No.: | PAB300-220D12&24-W | Brand Name: | PENGTU |
---|
Certification: | CE,ISO9001 |
---|---|
Specification: |
PAB-W Series 200-300W Power Modules 5V 12V 24V.Product details are as follows: ※Features ●Wide range of input voltage ●Broadband noise filter of input ●Surge suppress circuit of input ●Comply with UL 1950, IEC950 safety regulation ●Attractive outline design ●Terminal connection method ●Fast dynamic response Conditions:All specifications are tested under the room temperature 25℃, normal rated input voltage and pure negative normal load. |
Packaging & Delivery
Packaging: | Put in the carton and make transportation safety measures. |
---|---|
Delivery/Lead Time: | 15days |
Production Capacity: | 1000pieces/month |
Product Description
PAB-W Series 200-300W Power Modules 5V 12V 24V.Product details are as follows: ※Features
●Wide range of input voltage
●Broadband noise filter of input
●Surge suppress circuit of input
●Comply with UL 1950, IEC950 safety regulation
●Attractive outline design
●Terminal connection method
●Fast dynamic response
Conditions:All specifications are tested under the room temperature 25℃, normal rated input voltage and pure negative normal load.
※Input Characteristic
Voltage range
220VAC (Normal Rated Value): 100~2240VAC 176~264 VAC
※Output Characteristic
●Voltage set-point accuracy ……¯2%
●Line Regulation (Main) ……¯0.5%
●Load regulation (Main) ……¯0.5%
●Output Current Limited ……120%(Type)
●Output current ………3-60A for optional
●Output voltage ………5-48V
●Power …………200-300W
※General Characteristic
●Switching frequency ………100-200 KHz
●Isolation resistance ………200 MΩ
※Isolation voltage
●Input-output: >1500 VAC/MIN (Leakage current<5mA)
●Input-case: >1500 VAC/MIN (Leakage current<5mA)
●Output-case: >500 VDC/MIN
●Main-Vice: >500 VDC/MIN
※Environmental Characteristic
●Case Temperature ………………………Industry: -25-+85℃
Military I: -40-+85℃
Military II: -55-+85℃
●Storage temperature ……………………Industry: -45+105℃
Military: -55-+105℃
※Protection Features
●Input under voltage protection ●Output over current protection
●Output short circuit protection ●Over temperature protection
※Model selection
Input V. (Vac) Input V. range (vac) Output V.(V) Output Curr. (A) Ripple &noise pk-pk (mv) Efficiency (Typ) Models
SING 220 100-240/176-264 05 60 200 90% PAB300-220S05-W
220 100-240/176-264 12 25 120 91% PAB300-220S12-W
220 100-240/176-264 24 12.5 200 91% PAB300-220S24-W
220 100-240/176-264 48 6.25 300 92% PAB300-220S48-W
DUAL 220 176-264 05&24 15&8 100&200 81% PAB275-220D05&24-W
220 176-264 12&24 8.3&8.3 120&200 83% PAB300-220D12&24-W
220 176-264 12&19 8.3&10.5 120&190 83% PAB300-220D12&19-W
Triple 220 176-264 05&12&24 6&2&5 80&120&200 83% PAB180-220T05&12&24-W
220 176-264 05&12&24 6&6&6 80&120&200 83% PAB250-220T05&12&24-W
Remark:Only typical models are listed. For other models, please determine the power, input voltage and output voltage and send an email to *.
