PAB-C3 Series 150-300W AC DC Power Supply

PAB-C3 Series 150-300W AC DC Power Supply.Product details are as follows:
※Features
●Wide range of input voltage
●Broadband noise filter of input
●Surge suppress circuit of input
●Comply with UL 1950, IEC950 safety regulation
●Attractive outline design
●Terminal connection method
●Fast dynamic response
Conditions:All specifications are tested under the room temperature 25℃, normal rated input voltage and pure negative normal load.
※Input Characteristic
Voltage range
220VAC (Normal Rated Value): 176～264 VAC
※Output Characteristic
●Voltage set-point accuracy ……¯2%
●Line Regulation (Main) ……¯0.5%
●Load regulation (Main) ……¯0.5%
●Output Current Limited ……120%(Type)
●Output current ………3-30A for optional
●Output voltage ………5-48V
●Power …………150-300W
※General Characteristic
●Switching frequency ………100-200 KHz
●Isolation resistance ………200 MΩ
※Isolation voltage
●Input-output: >1500 VAC/MIN (Leakage current＜5mA)
●Input-case: >1500 VAC/MIN (Leakage current＜5mA)
●Output-case: >500 VDC/MIN
●Main-Vice: >500 VDC/MIN
※Environmental Characteristic
●Case Temperature ………………………Industry: -25-+85℃
                   Military I: -40-+85℃
                   Military II: -55-+85℃
●Storage temperature ……………………Industry: -45+105℃
                Military: -55-+105℃
※Protection Features
●Input under voltage protection         ●Output over current protection
●Output short circuit protection        ●Over temperature protection
※Model selection
Input V. (Vac) Input V. range (vac) Output V.(V) Output Curr. (A) Ripple &noise pk-pk (mv) Efficiency (Typ) Models
SING 220 176-264 05 30 100 85% PAB150-220S05-C3
220 176-264 12 20 120 87% PAB240-220S12-C3
220 176-264 24 10 200 88% PAB240-220S24-C3
220 176-264 28 10.7 280 88% PAB300-220S28-C3
220 176-264 48 6.25 300 89% PAB300-220S48-C3
DUAL 220 176-264 05&12 10&8 100&120 83% PAB150-220D05&12-C3
220 176-264 05&24 8&4 120&200 83% PAB150-220D05&24-C3
220 176-264 5&48 10&2 100&300 83% PAB150-220D05&48-C3
Remark:Only typical models are listed. For other models, please determine the power, input voltage and output voltage and send an email to *.
