Original SPECTRA S-CLASS SM-128 AA PRINTHEAD

SPECTRA S-CLASS SM-128 AA PRINTHEAD

The Spectra SE-128 AA is a high performance, robust and reliable jetting assembly designed for a broad range of wide format printers at resolutions up to 900 dpi. Two electrically independent piezoelectric slices, each with 64 addressable channels, are combined to provide a total of 128 nozzles. It has been calibrated for a droplet size of 30 pico litre and has a maximum firing frequency of 40 kHz.
This jetting assembly contains serial-to-parallel converters for selecting which jets to fire; all jets can be fired simultaneously or individually.
These Spectra SE-128 AA heads carries a manufacturer product warranty.

Specifications
- Technology: Piezo Electric
- Max. Resolution: 900 dpi
- Cal. Droplet Size: 30 pico litre
- Adj. Range for Droplet Size: 25-30 pico litre
- Tot. Amount of Nozzles: 128
- Nozzle Spacing: 508 microns
- Nozzle Diameter: 35 microns
- Firing Frequency: 40 kHz
- Operating Temperature: up to 90®C
- Ink Compatibility: Solvent and UV Inks

Note:
Gandinnovations / AGFA: Jeti printers use SE-128, SL-128 or SM-128 print heads depending on the original printer configuration. Please contact us for more information.

Agfa
Jeti 1224 UV HDC FTR
Jeti 2030 X-2 UV Flatbed
Jeti 3150 X-2 UV Flatbed
Jeti 3312 Solvent RTR
Jeti 3324 AquaJet RTR
Jeti 3324 Solvent RTR
Jeti 3324 UV RTR
Jeti 3348 Solvent HSS RTR
Jeti 3348 UV Galaxy RTR
Jeti 3348 UV Jetspeed RTR
Jeti 5024 Solvent RTR
Jeti 5024 UV JetSpeed RTR
Jeti 5048 UV XL JetSpeed

Dilli
Neo UV-LED GlassTech

Durst
Rho 320R
Rhopac 160

Graphics One
Fuzion UV

Inca
Columbia Turbo
Onset S20
Onset S70
Spyder 320
Spyder 320Q
Spyder V

Luscher
JetPrint 3530 UV

Spûhl
Virtu RS 25
Virtu RS 35
Virtu RS 36
Virtu RS 50
