Online Infrared Syngas Analyzer CO H2 CH4 CO2analyzer O2 analyzer

EU Authorization No.:
EP2796856 (B1)
US Authorization No.:
US9857323 (B2)
China Authorization No.:
ZL201110435862.3

• Modular sensor design ensures easy operation and maintenance.
• Standard 19’’ 3U industrial enclosure design, easily to be integrated into different kind of industrial systems.
• With LCD display to indicate all data index and tactile keypad easy for operation.
• Integrated RS232/RS485 digital output and 4-20mA analog output, easy to be acquired by project center controlling system and satisfy the continuous monitoring demand.
• Equipped with sample gas flow meter and needle valve to regulate the inlet gas flow and internal gas filter to protect the gas sensor from impurities.
• With constant temperature enclosure for NDIR and TCD sensors to avoid influence by temperature fluctuation and improve the measurement accuracy.
• With function of auto-zeroing with in-built auto-zero pump, efficiently decrease the calibration frequency.
• New generation modular syngas analyzer has equipped with a Bluetooth module. Assist with a Smartphone APP software, it can realize remote control, data download, and remote online diagnosis function in the near future.
• Adopt international advanced NDIR and TCD gas analysis technology.
• Can measure the concentration of CO, CO2, CH4, H2, O2, CnHm simultaneously.
• CnHm gas has no interference with CH4 measuring result.
• Precisely measure CO content in high concentration CO2
• H2 reading by patented Thermal Conductivity Detecting technology, with compensation for the interference effects of the CO, CO2 ,CH4 measured.
• No effect from flow fluctuation on H2 reading
• Online Heating Value calculation in real time, freely switchable between MJ / m¯ or kcal / m¯, and between HHV or LHV.
