Numa100,Numa120,Numa125 High Air Pressure DTH Down The Hole Hammers Bits

Price: US$ 1150
Minimum Order: 1 unit
Payment Terms: T/T
Port of Export: shanghai
Skype Me
Product Details
Model No.: Numa100,Numa120,Numa125 High Air Pressure DTH Down The Hole Hammers Bits Brand Name: Sandvik/New Diamond
Certification: ISO9001
Specification: Bit face shape selection:
1. Drop Center Bit
For high penetration rates in soft to medium hard and fissured rock formations. Low to medium air pressures. Maximum hole deviation control.
2. Concave Face
The all-round application bit face specifically for medium hard and homogenerous rock formations. Good hole deviation control and good flushing capacity.
3. Convex Face
For high penetration rates in soft to medium-hard with low to medium air pressures. It is the most resistance to steel wash, and may reduce the load and wear on the gauge buttons, but poor hole deviation control.
4. Double Gauge Face
This kind of face shape is suitable for fast penetration rates in medium to hard rock formations. Designed for high air pressures and good resistance to steel wash step gauge bit.
5. Flat Face Bit
This kind of face shape is suitable for hard to very hard and abrasive rock formations in applications with high air pressures. Good penetration rates an resistance to steel wash.

Carbide button shape selection:
1. Domed/Round Button
2. Parabolic/Semi-Ballistic Buttons
3. Ballistic Button
4. Sharp Button
5. Flat Button
Packaging & Delivery
Packaging: Inner package with cartons,outer package with wooden case
Delivery/Lead Time: 3 weeks
Production Capacity: 1000 unit/month
Product Description
1. 10 years manufacturing experience;
2. Certificate: ISO9001:2008
3. Material: Carbide

Based on the characteristics of the wells, oil, gas and construction drilling, our company self-designed, developed and manufactured this kind of high air pressure DTH hammer.

It has the following characteristics:

1. Using the latest rock drilling theory, optimizing the inside structure and the size of the air distribution, to make the DTH Hammer obtain the optimal energy transfer and make it achieve faster drilling speed and lower air consumption.
2. For such projects as the drill bit break, retrieving very difficult, we specially designed a safe and reliable anti-shedding device for the bit.
3. The check valve can be replaced to the one with bigger ail controlling hole to provide more efficient cuttings discharge.
4. The top sub and the drive chuck have special thread, which can achieve an easier disassemble.
Numa100,Numa120,Numa125 High Air Pressure DTH Down The Hole Hammers Bits
Numa100 Numa120 Numa125 High Air Pressure
Numa100 Numa120 Numa125 High Air Pressure
Numa100 Numa120 Numa125 High Air Pressure
Numa100 Numa120 Numa125 High Air Pressure
