Nucleon L Type Model Single Girder Gantry Crane Drawing

Why choose our L model single girder gantry crane?
Top quality Chinese brand crane
Siemens or Schneider world famous brand electricals
Soft start crane travelling motor
Overload protection function
European CE standard
Chinese best price

Working condition:

Working tempreture:-25-40®C
Work class: A5
Safety:

Overload protection
Main lifting motor with thermal protection
Hooks with latch
Rubber buffers
Protective earthing
Crane switch and travel end switch
Emergency switch can stop all movement when any dangerous happened
Sub-assemblies characteristic are tested before assembly
All cranes must be preassembled and tested before leaving factory and offer the certification of test.

Design: ‘YT’ Brand Electric L model gantry cranes are designed & manufactured accordance with ISO 9001:2000 ISO 14001:2004 and OHSAS 18001 considering factor of safety in respect to appropriate class of duty.

Motors: The motors are used specially crane duty suitable for frequent starting , reversing & braking in accordance with ISO 9001:2000 ISO 14001:2004.Motors are totally enclosed in dust proof construction foot / flange mounted TESC / TEFC , Sq. cage motors with integrated safety brakes, insulation class F, IP54 protection for hoisting, CT & LT motions.

Brakes: Independent Hydraulic Brake makes the crane safer and easier to control

Painting:Two coats of primer before assembly & two coats of synthetic enamel after testing

Color: according to your demand

Average thickness: about 100 microns

Gear Box: The entire gear boxes are made of accurate hob cut helical / spur gears & pinions having hardness 250 to 350 BHN made from carbon alloy steel. All gears & pinions running on antifriction type ball / roller bearings in totally are enclosed oil bath giving constant splash lubrication. The helical / Spur gear designed for adequate strength and optimum wear resistance for smooth operation & long life.

Wheel: The wheels of crane crab, main beam and end carriage are produced in our special Vacuum casting workshop (No sand inclusion technique) which makes our wheels more elastic and outer surface hard-wearing and durable.

Electrical Panel: Modular design, ease to install and maintain, reliable operation, fuses less circuitry, ducted wiring and compact terminals. Motor overload protection to prevent overloading.

Limit Switch: Safety limit switches for stoppers will be provided to prevent over traveling in all motions.

Design and construction rules:All the standards which are required for the crane are the Chinese standard.
