Nucleon General Industrial Using Single Girder Gantry Crane 10t Price

Brief Introduction of Nucleon General Industrial Using Single Girder Gantry Crane 10t

Nucleon hoist crane single girder gantry crane is used together with CD MD model electric hoists.
It is a track travelling type small and medium-sized crane. Its rated lifting capacity is 3 to 16 ton. The standard span of this Nucleon hoist crane single girder gantry crane is 12 to 30 meters. Its standard working temperature is -20℃~+40℃.My dear friend, according to your requirements, we can made the cantilever or not.


Application of Nucleon General Industrial Using Single Girder Gantry Crane 10t
This Nucleon hoist crane single girder gantry crane is a general crane, which is widely used in open ground and warehouses to grab materials.
Control Methods: ground control and cabin control.
Structure of Nucleon General Industrial Using Single Girder Gantry Crane 10t

The crane is composed of metal structure, cart operating mechanism, electric device and trolley (electric hoist). The surface of facing wind is very small, because of its steel-pip leg, and is characterized in light deadweight and strong hoisting capacity.


Safety system of Nucleon General Industrial Using Single Girder Gantry Crane 10t
1. Weight overload protection device.
2. Top quality long time bearing polyurethane materials buffer.
3. Crane travelling limit switch.
4. Voltage lower protection function.
5. Emergency stop system.
6. Current overload protection system and so on!


Features of Nucleon General Industrial Using Single Girder Gantry Crane 10t
Design: The cranes are designed & manufactured accordance with ISO 9001:2000 ISO 14001:2004 and OHSAS 18001 considering factor of safety in respect to appropriate class of duty.
Motors: The motors are used specially crane duty suitable for frequent starting , reversing & braking in accordance with ISO 9001:2000 ISO 14001:2004.Motors are totally enclosed in dust proof construction foot / flange mounted TESC / TEFC , Sq. cage motors with integrated safety brakes, insulation class F, IP54 protection for hoisting, CT & LT motions.
Brakes: Independent Hydraulic Brake make the crane more safe and easier to control
Gear Box : The entire gear boxes are made of accurate hob cut helical / spur gears & pinions having hardness 250 to 350 BHN made from carbon alloy steel. terminals. Motor overload protection to prevent overloading.
Wheels: The wheels of crane crab ,main beam and end carriage are produced in our special Vacuum casting workshop (No sand inclusion technic) ) which make our wheels more elastic and outer surface hard-wearing and durable.
Limit Switch: Safety limit switches for stoppers will be provided to prevent over traveling in all motions.
