Ningbo Tianze screw and barrel for food extruder machine
| Price: | US$ 1000 / Set |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | TT LC |
| Port of Export: | Ningbo |
Product Details
| Model No.: | Tianze001 Haitian | Brand Name: | Tizatech |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | Over 29 years experience in screw and barrel , more info pls find kaylee(at)tizatech.com |
Packaging & Delivery
| Packaging: | wooden case |
|---|---|
| Delivery/Lead Time: | 10 days |
| Production Capacity: | 300/week |
Product Description
Over 29 years experience in screw and barrel , more info pls find kaylee(at)tizatech.com
Specification:
Diameter: Ø15-Ø500
L/D ratio:15-55
Base Materials:
1)38CrMoAlA(SACM 645)
2)42CrMo(AISI 4140)
3)Cr12MoV(SKD11)
4)4Cr5MoSiV1(SKD61)
5)9Cr18MoV
6)40Cr
Bimetallic Alloy Materials:
1)Fe-based alloy
2)Ni-based alloy
3)Co-based alloy
4)Tungsten carbide
Processing Technology:
Heat treatment
High-frequency quenching
Nitriding treatment
Hard-chrome electroplating
Bimetallic alloy welding
Technical Parameter:
Nitrided layer depth:0.50-0.80mm
Nitrided hardness: 900-1100HV
Nitrided brittleness: Less than 2 level
Surface roughness: Ra 0.4
Linearity of screw: 0.015mm
Hard-chrome plating hardness: ≥950HV
Chrome-plating layer depth: 0.025~0.10mm
Bimetallic layer depth: 2 mm
Bimetallic hardness: HRC50-65
Material to be extruded:
PP, PE, PVC, ABS, AS, PS etc.
We can manufacture all types of screws and barrels according to clients' requirement.
|
