More Superhard product description:
More Superhard Company specializes in the production of all kinds of high-end ceramic bonded and metal boned CBN/diamond grinding wheels, honing stones and other abrasive products.
The selection of abrasives, grain size and hardness of ceramic bond diamond honing stone is in accordance with thematerials and surface finishing of workpieces. Cubic boron nitride (CBN) honing stones can machinestainless steel, high-strength steel, high-temperature alloy steel and heat-resistant steel etc.
Diamond honing stone is mainly used for fine grinding of automobile, diesel engine, motorcycle, tractor engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve, oil cylinder nozzle, air cylinder hole of compressor, the inner surface of the spline bore and cylinder hole and blind holeof other series.

Detail：
Diamond honing stone is mainly used for fine grinding of automobile, diesel engine, motorcycle,tractor engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve,oil cylinder nozzle, air cylinder hole of compressor, the inner surface of the spline bore and cylinder hole and blind hole of other series.

Materials of workpiece include cast iron, tool steel, die steel, hardened steel, high temperature alloy steel, copper, bronze, aluminum alloy, ceramic and so on.
Features of our honing stones:Dressing easily, 500 times longer in work life than that of traditional honing stones, 1-2 times higher in efficiency and finish
Detailed Specifications of our honing stones:
Model size grit
diamond and CBN honing stone L (mm) width (mm) height (mm) 0.8μm120#～150#
0.4μm150#～240#
0.2μm240#~W40#u
0.1μmW40#~W20#
0.05μm＜W20
16-35 2,3,4,6 2,3,4
40,50 2,3,3.5,4 1,1.5,2,2.5,3,3.5,4
60,70 1.5,2,3,3.5,6,8 2,2.5,3,3.5,4,6.5,7,8
80,90 3,4,5,6,8,9,9.5 3,4,5,6,7,8,10
100,120 2,3,5,6,8,9,12,15 3,4,5,6,7,8,10,12,15
140,150 3,5,6,8,9,12 4,5,6,7,8,10,12
200 8,10,15,20,40 8,10,15,20
Other specifications honing stone can be made according to customers' requirement. Email: *


Why choose our product
Our product’s advantages:
1.High grinding efficiency
2.Wonderful edge quality
3.Long service life
4.High polishing efficiency
5.Large Exports
6.Considerable after-sell service
7.Amazing performance
8.Various types and sizes available
9.Direct Factory Manufacturer
10.Backing/substrate material: Aluminum
11.Abrasive layer: diamond
12.Bond: vitrified
13.Excellent cutting edges
14.Reduced cycle times
15.Custom Engineered
