Medical Equipment, Digital Ultrasound Diagnostic Equipment
scroll left
  • Medical Equipment Digital Ultrasound Diagnostic Equipment
  • Medical Equipment Digital Ultrasound Diagnostic Equipment
scroll right

Medical Equipment, Digital Ultrasound Diagnostic Equipment

Price: US$ 999 / Set
Minimum Order: 1
Payment Terms: 25days
Port of Export: Shanghai
Skype Me
Product Details
Model No.: Digital Ultrasound Diagnostic Equipment Brand Name: MEDECO
Certification: CE,ISO
Specification: L 3.5MHz R60/R50 convex probe; Broadband, 2.0MHz-5.0MHz Multi-frequency;
L 7.5MHz L40 linear probe; Broadband, 5.0MHz-10.0MHz Multi-frequency;
L 6.5MHz R10/R13 Endo-cavity(Endo-vaginal) probe; Broadband, 5.0MHz-8.0MHz Multi-frequency;
L Other kinds of probes are optional on order request
(e. G. 3.5MHz R20 heart transducer; Wide bandwidth frequency, 2.0MHz-5.0MHz Multi-frequency)
Packaging & Delivery
Packaging: STANDARD EXPORT PACKAING
Delivery/Lead Time: 30days
Production Capacity: 5000PCS/Year
Product Description

Medical Equipment Digital ultrasound diagnostic equipment 5200
Ultrasound Scanner 5200

1. Ultrasound Scanner 5200 32channel digital ultrasound diagnostic equipment
2. Using black and white medical CRT display
3.80 element array double probe 156core interface.
4. Ultrasound main control system adopts embedded computer platform
5.2 probe connector support, the following probes are supported:
L 3.5MHz R60/R50 convex probe; Broadband, 2.0MHz-5.0MHz Multi-frequency;
L 7.5MHz L40 linear probe; Broadband, 5.0MHz-10.0MHz Multi-frequency;
L 6.5MHz R10/R13 Endo-cavity(Endo-vaginal) probe; Broadband, 5.0MHz-8.0MHz Multi-frequency;
L Other kinds of probes are optional on order request
(e. G. 3.5MHz R20 heart transducer; Wide bandwidth frequency, 2.0MHz-5.0MHz Multi-frequency)
6. Beamformer:
L Full Digital BeamFormer(DBF)
L Full digital beamformer (DBF)
L Real-time dynamic aperture(RDA)
L Dynamic receiving focus(DRF)
7. Dynamic frequency scanning(DFS), frequency 2.0-12.0MHz(depending on broadband probe), can provide 4 multi-frequency.
8. Tissue Harmonic Imaging (THI) technique.
9. Display model: B, 2B, 4B, B/M, M.
10. Dynamic Range ≥100dB, 4 steps changeable.
11. Image processing technology: Controllable frame correlations, gamma correction, edge enhancement, image smooth, image denoise, automatic gain control, Image rotation in angle 90®/180®/270®, image black-white reverse & histogram display, etc...
12. Image zoom: Stepless enlargement, and real-time picture in picture (PIP) zoom.
13. Cine playback; Large volume cine playback (automatically or manually); Split screen cine playback (4B, 9B), B/M, M mode cine playback(automatically or manually).
14. Image management system: Image archive, browse, compare, save, print, transport; Capable of storing up to hundreds of thousands of images, thousands of cine loops; Can slide show stored images in full screen.
15. Measurement and calculation: Distance, ellipse measure circumference and area, trace measure circumference and area, ellipse measure surface area and volume; 4 measuring results; Ratio measurement, line narrow/width ratio, area narrow/width ratio, angle measurement, automatic calculation.
16. Assistant tools: Piercing guide, histogram display, cross section display.
17. Menu interface, Real-time online help and guide system.
18. Full screen character input; Multi-directional arrow indicator.
19. Tens of bodymarks selectable, intelligent changeable along with examining department.
20. Medical information database system, Patient information storage, search and management.
21. Formula setting and selective system for diagnosis measurement, selectable according to difference ethnic groups.
22. Automatic measurement software for obstetrics, gynecology, organ, heart, urology etc. Department.
23. Multiple kinds of obstetric measurement reports, fetus physiological grading report, fetus growing curves.
24. Automatic report producing system for gynecology, organ, heart and urology department.
25. Optional 3D Module.
26. Expansion interfaces:

L VGA, S-Video, TV Interface
L USB2.0 Interface
L RJ-45 Network interface
L Flexible storage media
L Support DeskJet printer, LaserJet printer, video printer and video recorder
