Magnetic Stripe MMS Series
| Price: | US$ 1 / Roll |
|---|---|
| Minimum Order: | 300 sheets |
| Payment Terms: | T/T, Western Union, Paybal, etc. |
| Port of Export: | Shanghai Port |
Product Details
| Model No.: | MMS | Brand Name: | MK |
|---|
| Certification: | |
|---|---|
| Specification: | The Magnetic Stripe MMS series are being widely used in magnetic cards including telecom card, identification card, and loyalty card, etc. It features good performance in temperature resistance, anti-corrosion and long durability. The products are suitable for lamination technology in card production. |
Packaging & Delivery
| Packaging: | 16 Rolls per carton |
|---|---|
| Delivery/Lead Time: | 10-25 Work days |
| Production Capacity: | 50000 rolls per week |
Product Description
Technical parameters:
Coercivity: 219kA/m（2750 oe）HiCo / 28.7kA/m（360 oe LoCo
Square ratio K: ≥0.8
Base film material: Polyester film
Magnetic layer material: Barium Ferrite /
Color: Black
Base film thickness：（12«1）¯°±²³´µm
Total thickness：（26~29）¯°±²³´µm
Signal Amplitude Characteristics:
Signal amplitude UA1：80~130% UR
Signal amplitude Ui1：≤136% UR
Signal amplitude UA2：≥80% UR
Signal amplitude Ui2：≥65% UA2
Resolution UA3：≥70% UA2
Erasure UA4：≤3% UR
Extra pulse Ui4：≤5% UR
Wear Resistance Characteristics:
Average signal output amplitude: UA after≥60% UA before
Individual signal output amplitude：Ui after≥80% Ui before
Durability：≥2000 times
Chemical Resistance Characteristics:
Average signal output amplitude: UA after≥90% UA before
Individual signal output amplitude: Ui after≥90% Ui before
Storage Condition：
The allowed storage period for the magnetic stripe reel is 3 years at temperature 10~30℃ with humidity 40%~60%RH. Heavy pressing is strictly prohibited. The maximum number of cases to be accumulated is 6.
Keep the magnetic stripe reel far away from the magnetic field.
Handle with care and avoid fierce vibration;
Keep it unexposed to sun and rain.
|
