MT6070iH5WV old type fully replaced by 7'' HMI MT6071IP touch panel MT6070iH5 new and original
| Price: | US$ 110 |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | TT/WESTERN UNION/PAYPAL |
| Port of Export: | ShenZhen or HongKong |
Product Details
| Model No.: | MT6071IP | Brand Name: | Weinview |
|---|
| Certification: | CE UL |
|---|---|
| Specification: |
PCB Coating N/A
Enclosure Plastic Dimensions W*H*D 200.4*146.5*34mm Panel Cutout 192*138mm Weight Approx.0.52kg Mount Panel mount |
Packaging & Delivery
| Packaging: | 1 |
|---|---|
| Delivery/Lead Time: | 3-5 DAYS |
| Production Capacity: | 9999 |
Product Description
Order NO. MT6071IP
Display 7 TFT
Resolution 800*480
Brightness 300
Contrast Ratio 500:01:00
Backlight Type LED
Backlight Lige Time >30,000hrs
Colors 16M
LCD Viewing Angle(T/B/L/R) 70/50/70
Type 4-wire Resistive Type
Accuracy Active Area Length(X)¯2% Width(Y)¯2%
Flash 128MB
RAM 128MB
32bits RISC Cortex-A8 600MHZ
I/O Ports USB Host USB 2.0x1
USB Client USB 2.0x1(Micro USB)
Ethernet N/A
COM Port COM1:RS-232 4W COM2:RS-485 2W/4W
RTC Built-in
Power Input Power 10.5 ～ 28VDC
Power Isolation Built-in
Power Consumption 1A @12VDC; 500mA @24VDC
Voltage Resistance 500VAC(1 min.)
Isolation Resistance Excees 50MΩat500VDC
Vibration Endurance 10 to 25HZ(X,Y,Z direction 2G 30minutes)
Environment Protection Structure NEMA4/IP65 Compliant Front Panel
Storage Temperature .-20℃ ～ +60℃(-4～ 140f
Operating Temperature 0℃～50℃ （32～122 F)
Relative Humidity 10%～90%(non-condensing)
Certificate CE CE marked
UL
Software EasyBuilder Pro
|
