LM501349 Tapered Roller Bearing 41.275*73.4314*23.0124mm

LM501349 Tapered Roller Bearing 41.275*73.4314*23.0124mm
Product Description
LM501349 Tapered Roller Bearing Description
Specification Dimensions
Design Units Metric d-Bore Diameter 41.275mm
Structure Roller Bearing D-Outer Diameter 73.4314mm
Weights 367.41g Precision Rating P5 P6 P4 P2 P0
Cage Material Brass Cage Clearance C2 C3 C4 C5 C0
Material Chrome Steel GCR15
Ball Type GCR15 Steel H-Total Width 23.0124mm
Seals Type Open Basic Load Ratings
Certificate ISO9001:2008 Cr Dynamic Load Rating 74730.1N
Feature The steeper the cup angle, the greater the ability of the bearing to handle thrust loads. C0r Static Load Rating 74285.3N
Number of Rows Single Specifications/Environment Standard
LM501349 Tapered Roller Bearing Features
Its conical roller geometry permits a static load rating (Cor) of 74285.3N and a dynamic load rating (Cr) of 74730.1N. The bearing has an inside diameter (ID) of 41.275 mm, an outside diameter (OD) of 73.4314 mm, and a width of 23.0124 mm.

Its chrome steel cage prevents the rollers from coming into contact with each other during use, reducing friction, vibration, and noise, and its unsealed design allows for lubrication in place. A complete single tapered roller bearing assemblies are generally mounted in opposing pairs on a shaft to evenly distribute loads.

This tapered roller bearing is suitable for use in applications such as agricultural machinery, construction and mining equipment, axle systems, and engine motors. Roller bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads.

These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All roller bearings are open, shielded, or sealed. Sealed bearings are lubricated with oil or grease in the bearing factory, while open and shielded bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use.

LM501349 Tapered Roller Bearing Application
Aerospace, agriculture, automotive, heavy truck, cement, aggregate, coal, oil and gas, construction, gear drives, machine tools, mining, paper, metals, rail, and wind.
