Insulation thermal mortar production line,glazed hollow beads mixer machine,vitrified hollow bead

Insulation thermal mortar production line,glazed hollow beads mixer machine,vitrified hollow bead of thermal insulation mortar equipment


Glazed beads of thermal insulation materials production line mainly by the hybrid systems, storage systems, copolymer material hybrid systems, conveyor systems, metering systems, packaging systems, dust removal system and other accessories.
Master batch mixing system: based on gravity mixer, for mixing of the masterbatch;
Storage System: used to store vitrified (hollow) beads, finished masterbatch;
Copolymer material mixed system: the glass of the (hollow) beads dedicated centrifugal mixer for the main set of streaming, Tuochen technology in one;
Delivery system: Masterbatch products rely on bucket elevator conveyor to the high feed tank storage, glass (hollow) beads rely on vacuum conveying system to transport material mixed copolymer system, at least to reduce the crushing of raw materials;
Measurement system: automatic measurement of formulation;
Packaging system: specific gravity drop, frangible pellet packaging machine;
Dust removal system: pulse jet bag filter.

vitrified beads thermal insulation mortar mixer adopts the pioneering zero broken technique to overcome the bulk density increase of particles in various aspects, do not damage the original state of materials, ensure the product's insulation indexes. Besides,the drive roll drives the mixing drum,and the lifting blades on drum wall will flip and throw the materials in a wide range, adding the drum design, the vitrified beads broken rate to a minimum. so that the materials can be mixed evenly and it greatly improves the vitrified beads slurry heat preservation effect.It can efficiently and rapidly mix materials.




Features:
1. Effective security control system, professional electrical design, quality assurance;
2. Wear-resisting durable powder conveying system and accurate weighing system;
3. Sewing platform design and packing machine and pneumatic packing machine are suitable for packaging of insulation mortar;
4. Unique sealing of feed discharging mouth, prevent leakage powder;
5. Customized dust collector system, green and environmental protection, create a good working environment for you;
6. Short installation period, low installation cost.
7.one component of inorganic insulation mortar production line, thermal insulation mortar production line ribbon outer ring and the inner wall of the casing clearance are adjustable, and a cleaning door, no residue production. Accelerate mixing speed.
One component of inorganic thermal insulation mortar production line, the production line structure:
Double seal spiral circulation, stirring time 5--8 minutes, even degree over 95%, discharging time 5--10 minutes. Weight: 800--900KG. Material: steel plate thickness: 3--4mm. Spindle speed: 1400 r/pm.
