IR centrifugal hot water circulating pump

IR horizontal centrifugal hot water pump is used to transfer the hot with temperature less than 120 DegC.

IS Series single stage single suction end suction horizontal centrifugal pump is the energy-saving pump to substitute BA series and B series single stage clear water centrifugal pump.
Advantages: reasonable hydraulic structure and convenient maintenance and good suction height and high efficiency etc. The pump is suitable for water supply and discharge in industry and city and gardening in farm. It is used to transport clear water and other liquids which is similar to clear water in physical and chemical characteristic. Liquids temperature is not higher than 120℃.​

Parameter:

Model Capacity
mз/h Head
m Speed
r/min Power
KW Caliber mm
Inlet Outlet
IS50-32-125 12.5 20 2900 2.2 50 32
6.3 5 1450 0.55 50 32
IS50-32-160 12.5 32 2900 3 50 32
6.3 8 1450 0.55 50 32
IS50-32-200 12.5 50 2900 0.5 50 32
6.3 12.5 1450 0.75 50 32
IS50-32-250 12.5 80 2900 11 50 32
6.3 20 1450 1.5 50 32
IS65-50-125 25 20 2900 3 65 50
12.5 5 1450 0.55 65 50
IS65-50-160 25 32 2900 5.5 65 50
12.5 8 1450 0.75 65 50
IS65-40-200 25 50 2900 7.5 65 40
12.5 12.5 1450 1.1 65 40
IS65-40-250 25 80 2900 15 65 40
12.5 20 1450 2.2 65 40
IS65-40-315 25 125 2900 30 65 40
12.5 32 1450 4 65 40
IS80-65-125 50 20 2900 5.5 80 65
25 5 1450 0.75 80 65
IS80-65-160 50 32 2900 7.5 80 65
25 8 1450 1.5 80 65
IS80-50-200 50 50 2900 15 80 50
25 12.5 1450 2.2 80 50
IS80-50-250 50 80 2900 22 80 50
25 20 1450 3 80 50
IS80-50-315 50 125 2900 37 80 50
25 32 1450 5.5 80 50
IS100-80-125 100 20 2900 11 100 80
50 5 1450 1.5 100 80
IS100-80-160 100 32 2900 15 100 80
50 8 1450 2.2 100 80
IS100-65-200 100 50 2900 22 100 65
50 12.5 1450 4 100 65
IS100-65-250 100 80 2900 37 100 65
50 20 1450 5.5 100 65
IS100-65-315 100 125 2900 75 100 65
50 32 1450 11 100 65
IS125-100-200 200 50 2900 45 125 100
100 12.5 1450 7.5 125 100
IS125-100-250 200 80 2900 75 125 100
100 20 1450 11 125 100
IS125-100-315 200 125 2900 110 125 100
100 32 1450 15 125 100
IS125-100-400 100 50 1450 30 125 100
IS150-125-250 200 20 1450 18.5 150 125
IS150-125-315 200 32 1450 30 150 125
IS150-125-400 200 50 1450 45 150 125
IS200-150-250 400 20 1450 37 200 150
IS200-150-315 400 32 1450 55 200 150
IS200-150-400 400 50 1450 90 200 150
