Hydraulic casing hanger

It is hdraulically set by applying pressure through the run-in string.A setting ball is circulated or dropped to a ball seat built into the landing collar.Applied pressure acts on the internal piston and moves slips up the cone to the set position.


Hydraulic liner hangerHome Products Liner hanger series Hydraulic liner hanger
DYX-C HYDRAULIC LINER HANGERSSX-A MECHANICAL LINER HANGER
DYX-C HYDRAULIC LINER HANGER
DYX-C HYDRAULIC LINER HANGER
DYX-C HYDRAULIC LINER HANGER
DYX-C HYDRAULIC LINER HANGER
DYX-C HYDRAULIC LINER HANGER
DYX-C HYDRAULIC LINER HANGER
DYX-C HYDRAULIC LINER HANGER
DYX-C HYDRAULIC LINER HANGER
DYX-C HYDRAULIC LINER HANGER
PresentationThe DYX-C is hdraulically set by applying pressure through the run-in string.A setting ball is circulated or dropped to a ball seat built into the landing collar.Applied pressure acts on the internal piston and moves slips up the cone to the set position. Product featureFeatures:
1、The DYX-C is to be set hydraulicall,which is designed for applications in all types of wells.
2、Working with SQ setting-ball carrier,the DYX-C is suitable for applications in horizontal or highly-deviated wells.
3、The piston sealing element is made of nitrile/fluorine rubber for high pressure and temperature ratings.
4、Main parts are fabricated with high-strength alloy steel providing high burst/collapse resistance.

Parameters

Specification,mm Φ244.5 X Φ177.8mm/Φ139.7mm Φ177.8 X Φ127mm/Φ114.3mm
Rated Load,t 120 50
Sealing Capacity,MPa 25 25
Shearing Pressure of Pins in Cylinder,MPa 7~8 7~8
Casing Wall Thickness,mm 10.03 9.19
11.05 10.36
11.99 11.51
Casing Weight,KG/m 59.52 38.69
64.73 43.15
69.94 47.62
Body Max O.D.,mm 215 152
Body Min I.D.,mm 155 108
