Huawei rectifier module R4850N6
| Price: | US$ 88 / Piece |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | T/T |
| Port of Export: | ShenZhen |
Product Details
| Model No.: | R4850N6 | Brand Name: | Huawei |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Huawei rectifier module R4850N6
R4850N6 is a high-efficiency, high-power-density digital rectifier module, which realizes the conversion of 85V AC ~ 300V AC input and 53.5V DC default output. It has the characteristics of high reliability, high conversion efficiency, low noise, etc., and has perfect input protection, output protection, soft start, hot plugging and other functions. It can form a large-capacity rectified power supply in parallel. The latest power monitoring technology is used to implement the monitoring of the status of the rectifier module and the load, and the output voltage can be adjusted through the background. |
Packaging & Delivery
| Packaging: | 1 pc/ctn |
|---|---|
| Delivery/Lead Time: | 6 |
| Production Capacity: | 666 |
Product Description
Huawei rectifier module R4850N6
AC INPUT RANGE
85 - 300 VAC (45 - 65 Hz)
Current (maximum) @ nominal input, full load
≤17A
Output Voltage (adjustable range)
42~58VDC Default value: 53.5VDC
Power (maximum) @ nominal input
3000W (176~300VAC)
Efficiency
>93％
Dimension
40.8(H)×105(W)×281(D)mm
Weigh
≤2kg
FEATURES：
Efficiency is greater than 93%
Wide input voltage range of 85 ～ 300VAC
Operating temperature range -40 ℃ ～ + 75 ℃
Total harmonic distortion (THD) ≤5%
Support online hot plug function
Full digital control
Support intelligent Electricity meter
Support CAN communication
Support LED indication alarm
Support voltage, current, and current sharing functions
Meet RoHS requirements
Pass TUV, CE, UL, FCC, CB certification
|
